Why Choose the ABB MPD14-11R Double Pushbutton?
The ABB MPD14-11R is an illuminated double pushbutton operator designed for industrial machinery, control panels and operator stations. As part of the ABB MPD modular pilot device range, it combines ON and OFF control functions with visual indication in a compact operator suitable for standard industrial panel mounting.
The MPD14-11R features a green flush upper pushbutton marked “ON” and a red extended lower pushbutton marked “OFF”. A red indicator light provides visual signalling when the operator is assembled with the appropriate ABB illumination unit, while the extended lower actuator provides clear physical differentiation between the two command functions.
Designed for a standard 22.5 mm mounting hole, the MPD14-11R provides IP66 protection and is suitable for ambient operating temperatures from -25 to +70 °C. Contact sets and the illuminating unit are ordered separately as part of ABB's modular pilot-device system. ABB order code 1SFA611143R1101 identifies this exact MPD14-11R Double Pushbutton within ABB product group 312001-Pilot Devices (Secrl).
Key Advantages
- Compact double pushbutton operator combines ON and OFF commands in one panel position.
- Green ON upper button and red OFF lower button provide intuitive machine-control identification.
- Flush upper and extended lower actuator arrangement provides clear tactile differentiation.
- Red indicator light supports visual machine-status signalling.
- IP66 protection supports dependable operation in demanding industrial environments.
- Standard 22.5 mm panel mounting simplifies integration into control panels and machinery.
- Modular construction allows compatible ABB contact sets and illumination components to be selected separately.
Key Features
- ABB MPD14 modular double pushbutton.
- Green flush upper pushbutton marked ON.
- Red extended lower pushbutton marked OFF.
- Red indicator light.
- Illuminated operator design.
- Flush/extended actuator configuration.
- 22.5 mm mounting hole diameter.
- IP66 protection rating.
- Ambient operating temperature range of -25 to +70 °C.
- Contact sets and illuminating unit are ordered separately.
- Operator weight of approximately 0.025 kg.
- ABB order code 1SFA611143R1101.
Compact ON/OFF Control with Visual Indication
Double pushbuttons provide two related control commands within a single operator position, helping machine builders conserve valuable control-panel space. The ABB MPD14-11R combines a green ON upper actuator with a red OFF lower actuator, providing an immediately recognisable interface for machine operation, while the extended lower button makes the two controls easier to distinguish by touch.
The red indicator adds a visual signalling function when the operator is combined with an appropriate ABB illumination unit. ABB's modular pilot-device architecture allows compatible holders, contact sets and illumination components to be selected according to the electrical requirements of the application, providing a flexible solution for industrial machinery and automation systems.
Typical Applications
- Industrial machinery ON/OFF control stations.
- Manufacturing and production equipment.
- Conveyor and material handling systems.
- Machine control panels and operator stations.
- Process machinery and automation equipment.
- Control desks and local operator interfaces.
- OEM machine-building applications.
