Why Choose the ABB CP3-10R-02 Compact Pushbutton?
The ABB CP3-10R-02 is a compact and robust momentary industrial pushbutton designed for machinery, automation systems and electrical control panels. Part of the ABB CP3 Compact pushbutton range and ABB product group 311530-Compact Pushbuttons, its all-in-one construction combines the operator and electrical contacts to support efficient panel installation.
The CP3-10R-02 features a red, extended, non-illuminated actuator with a black plastic bezel. Its momentary spring-return action operates integrated 2 normally closed (NC) contacts, making it suitable for industrial command and control circuits requiring two normally closed switching paths.
Designed for standard 22 mm panel mounting, the CP3-10R-02 uses screw terminals for secure electrical connections. Its IP66, IP67 and IP69K front protection, compact 30 × 30 × 60 mm dimensions and operating temperature range of -25 to +70 °C support reliable use in demanding industrial environments.
Key Advantages
- Compact momentary pushbutton for industrial machinery and automation control.
- Red extended actuator provides clear identification and convenient operation.
- Integrated 2 normally closed (NC) contacts provide two NC switching paths.
- Spring-return operation automatically restores the normal contact state after release.
- High front protection with IP66, IP67 and IP69K ratings.
- Standard 22 mm panel mounting simplifies integration into control panels and operator stations.
Key Features
- ABB CP3 Compact pushbutton series.
- Momentary / spring-return switching function.
- 2 normally closed (NC) contacts.
- Red extended pushbutton actuator.
- Black plastic bezel.
- Non-illuminated operator design.
- 22 mm panel mounting.
- Screw terminals with 0.8 N·m tightening torque.
- Rated insulation voltage of 300 V.
- Rated impulse withstand voltage of 6 kV.
- Mechanical durability of 0.5 million operations.
Reliable Momentary Control for Industrial Machinery
Momentary pushbuttons provide operators with a direct method of issuing temporary commands to machinery and electrical control systems. The ABB CP3-10R-02 uses a spring-return mechanism, so the actuator automatically returns to its normal position when released.
The integrated 2NC contact arrangement provides two normally closed switching paths that change state while the pushbutton is operated and return to their normal state when the actuator is released. Combined with its extended actuator, standard 22 mm mounting format and high front protection, the CP3-10R-02 is well suited to industrial control panels, operator stations and automated machinery.
Typical Applications
- Industrial machinery control panels.
- Momentary command and control circuits.
- Machine operator stations.
- Factory automation equipment.
- Production and processing machinery.
- Electrical control cabinets and operator interfaces.
