Why Choose the ABB C2SS2-10B-11 Compact Selector Switch?
The ABB C2SS2-10B-11 is a compact black 2-position maintained selector switch designed for machine control, operating-mode selection and industrial automation applications. Part of ABB's Compact pilot-device range, it combines the selector operator and switching contacts in an efficient all-in-one assembly.
This model features a black short-handle actuator, 2-position maintained operation and 1 normally open plus 1 normally closed (1 NO + 1 NC) contact. The maintained mechanism keeps the selected position until the operator deliberately moves the handle, making it suitable for persistent machine and process selections.
The C2SS2-10B-11 is non-illuminated and features a black plastic bezel. Designed for standard 22 mm panel mounting, its compact construction and high resistance to dust and water provide a practical selector-control solution for industrial machinery, operator stations and control panels.
Key Advantages
- 2-position maintained selector switch for persistent control selections.
- Black short-handle actuator provides straightforward rotary operation.
- Integrated 1 NO + 1 NC contact configuration provides complementary switching.
- Black plastic bezel provides a compact industrial panel interface.
- Standard 22 mm panel mounting supports straightforward integration.
- Non-illuminated design is ideal where separate visual indication is not required.
- ABB Compact all-in-one construction helps reduce installation time and panel assembly complexity.
Key Features
- ABB C2SS2 Compact selector switch.
- 2-position selector.
- Maintained operation.
- Black short-handle actuator.
- Non-illuminated design.
- 1 normally open + 1 normally closed contact.
- 24–300 V operational voltage range.
- 300 V rated insulation voltage.
- Black plastic bezel.
- Standard 22 mm panel mounting.
- Compact all-in-one pilot-device construction.
Reliable Maintained Selection for Industrial Control
Maintained selector switches allow an operator to choose a control state that remains selected until the handle is deliberately moved again. The ABB C2SS2-10B-11 provides two selectable positions, making it suitable for operating-mode selection, function enabling and other persistent industrial control commands.
Its integrated 1 NO + 1 NC contacts provide complementary switching from a single operator, while ABB's Compact all-in-one construction simplifies panel assembly. The black short handle, black plastic bezel and standard 22 mm mounting format make the C2SS2-10B-11 a practical choice for industrial operator interfaces.
Typical Applications
- Industrial machinery mode selection.
- Operator control stations and consoles.
- Factory automation equipment.
- Motor and process control panels.
- Production and packaging machinery.
- Material handling and conveyor systems.
