Why Choose the ABB E219E48 Indicator Light?
The ABB E219E48, product type E219-E48, is a compact DIN-rail indicator light with yellow LED illumination designed to provide clear visual indication of electrical operating conditions. Part of the ABB E219 / E210 command and signalling range, it provides a space-efficient signalling solution for distribution boards, control panels and electrical installations.
The E219-E48 operates across a 12–48 V AC/DC voltage range and incorporates two yellow LEDs for visual signalling. Its AC/DC compatibility makes it particularly suitable for low-voltage control, automation and auxiliary circuits where yellow indication is required for abnormal operating states, warnings or other application-defined conditions.
At only 9 mm wide, equivalent to 0.5 modular spacing, the E219-E48 occupies minimal DIN-rail space. Its low 0.40 W power loss, IP20 protection and maintenance-free LED technology make it well suited to continuous status indication in commercial, industrial and building-services electrical systems.
Key Advantages
- Clear yellow LED indication for highly visible electrical status signalling.
- Flexible 12–48 V AC/DC voltage range for low-voltage circuits.
- Two integrated yellow LEDs for visual indication.
- Low 0.40 W power loss for efficient continuous operation.
- Compact 9 mm width equivalent to 0.5 modular spacing.
- IP20 protection rating for installation within suitable electrical enclosures.
- Maintenance-free LED technology for reliable long-term indication.
- Designed for straightforward DIN-rail installation in modular electrical equipment.
Key Features
- ABB E219 / E210 command and signalling range.
- E219-E48 modular indicator light.
- Yellow LED visual indication.
- Two integrated LEDs.
- 12–48 V AC/DC voltage range.
- 48 V rated voltage.
- 50/60 Hz rated frequency.
- 0.40 W power loss.
- IP20 degree of protection.
- Compact 0.5-module, 9 mm-wide construction.
- Suitable for central indication of electrical equipment operating states.
Low-Voltage Yellow LED Status Indication
ABB E219 indicator lights are designed to provide a clear overview of electrical equipment operating conditions from a central location. The yellow LEDs in the E219-E48 provide an easily recognisable visual signal suitable for abnormal-operation indication, warnings, phase conditions or other functions defined by the electrical system designer.
The 12–48 V AC/DC operating range makes the E219-E48 particularly suitable for low-voltage control and auxiliary circuits. Combined with efficient LED technology, a low 0.40 W power loss and a housing only 9 mm wide, it provides effective visual signalling while conserving valuable DIN-rail space.
Typical Applications
- Low-voltage AC/DC command and signalling circuits.
- Electrical distribution boards and control panels.
- Warning and abnormal-operation indication.
- Operating-state indication for electrical equipment.
- Phase-presence and phase-loss signalling.
- Industrial automation and auxiliary circuits.
- Building-services control systems.
- Centralised visual status indication.
