Lovato Electric 8LM2TB7122 electrical installation component for professional commercial and industrial assemblies, suitable for maintenance, replacement and panel building applications.
Original price was: £12.39.£8.67Current price is: £8.67.
The Lovato 8LM2TB7122 is a professional 22mm metal double touch pushbutton actuator designed for reliable industrial control panels, automation systems and machine operator interfaces. Part of the Lovato 8LM metal series, this actuator features two flush spring-return pushbuttons with a black and red I-O configuration for clear operator identification and dependable manual control.
Built using a durable aluminium and zinc alloy construction, the 8LM2TB7122 provides excellent mechanical performance for demanding industrial environments. The dual pushbutton arrangement allows convenient control functions from a single compact panel position while maintaining a clean and organised control layout.
With a 22mm mounting diameter, IP40 protection rating and both buttons configured with spring-return operation, the Lovato 8LM2TB7122 is suitable for electrical cabinets, machinery control stations and industrial automation applications requiring dependable operator input devices.
The Lovato 8LM2TB7122 provides an efficient solution for applications requiring two manual control functions within a single compact operator device. The dual spring-return pushbutton arrangement enables quick operator interaction while maintaining a professional control panel appearance.
The Lovato 8LM series is designed for machine builders, electrical panel manufacturers and automation professionals requiring durable, modular and space-efficient control components for industrial systems.
| IP Rating | IP40 |
|---|---|
| Weight [g] | 44 |
| Qty. per package | 5 |
| Multiple qty. of packs per order | 5 |
| Package dimensions [mm] | 065X046X090 |
| Volume [cm³] | 53.82 |
| Bar code [EAN13] | 8013975144275 |
| HS Code | 85365080 |
| Product designation | Double-touch actuators, spring return - Two flush push-button |
| Product type designation | 8LM2TB71 |
| Colour | Black/Red |
| Material | Aluminium and zinc alloy |
| IEC degree of protection | IP40 |
| Operating force | 0.8kg/1.7Ib |
| Mechanical life | 1000000 |
| Mounting adapter | LM2TAU120 |
| UL degree of protection | Type 1 |
| min [°C] | -40 |
| max [°C] | +70 |
| ETIM 8.0 | EC000221 - Front element for push button |
The Lovato 8LM2TB7122 is a double touch pushbutton actuator used for manual operator control in industrial automation and electrical panels.
The actuator includes two flush spring-return pushbuttons in a black and red I-O configuration.
The actuator is designed for 22mm panel mounting systems commonly used in industrial control equipment.
The actuator has an IP40 protection rating for use in suitable protected control panel environments.
The Lovato 8LM2TB7122 provides a mechanical life of approximately 1,000,000 operating cycles.
