8LM2TSL1204 – RED ILLUMINATED KNOB SELECTOR ACTUATOR 2

Q: How many positions does this selector switch have?

The actuator has two positions: 0-1, providing simple selector control operation.

Q: What colour is the illuminated selector?

The 8LM2TSL1204 features a red illuminated selector knob for clear operator indication.

Q: What mounting size is required?

The actuator is designed for standard Ø22 mm panel mounting applications.

Q: What protection rating does this selector actuator provide?

The actuator provides IP65 front protection when installed correctly, making it suitable for industrial control applications.

Lovato Electric 8LM2TSL1204 electrical installation component for professional commercial and industrial assemblies, suitable for maintenance, replacement and panel building applications.

SKU: 8LM2TSL1204MPN: 8LM2TSL1204

Why Choose the Lovato 8LM2TSL1204 Illuminated Selector Switch Actuator?

The Lovato 8LM2TSL1204 is a compact and reliable illuminated selector switch actuator designed for industrial control panels, automation systems and machine operator interfaces. Part of the Lovato 8LM metal selector switch series, this Ø22 mm actuator provides clear visual indication and dependable manual control with a two-position selector mechanism.

Designed for demanding industrial applications, the 8LM2TSL1204 features a durable aluminium and zinc alloy construction with a compact panel-mounted design. Its illuminated red selector knob allows operators to quickly identify the selected operating status while providing reliable control in electrical cabinets and automation equipment.

The selector actuator features a two-position 0-1 configuration with a red illuminated selector knob. It is suitable for applications requiring clear status indication alongside reliable selector switch operation in industrial environments.

Key Advantages

Illuminated selector switch actuator for industrial control applications.
Ø22 mm mounting size suitable for standard electrical control panels.
Clear red illuminated operator indication.
Two-position 0-1 selector operation.
Durable metal construction for industrial environments.
Long mechanical life for dependable operation.

Key Features

Lovato 8LM metal selector switch series.
Illuminated selector switch actuator.
Two positions: 0-1.
Red illuminated knob.
Ø22 mm panel mounting diameter.
Aluminium and zinc alloy construction.
Suitable for LED illumination applications.
Designed for industrial operator interfaces.

Reliable Illuminated Switching for Industrial Control Systems

Illuminated selector switches provide operators with immediate visual feedback about machine status or selected operating modes. This improves usability and helps reduce incorrect operation in industrial environments.

The Lovato 8LM series is designed for automation engineers, electrical panel builders and OEM machine manufacturers requiring dependable operator controls. The 8LM2TSL1204 combines robust construction, compact installation and clear illuminated indication.

Typical Applications

Industrial electrical control panels.
Machine automation systems.
Motor control cabinets.
Production and manufacturing equipment.
OEM machinery control stations.
Industrial operator interfaces.

Technical Specifications

Tick the specs you need, then view products that match.

Illumination	Illuminated
Product Series	Lovato 8LM Metal
Mounting Diameter	22 mm
Device Type	Selector Switch
IP Rating	IP40
Colour	Red
Weight [g]	25
Qty. per package	10
Multiple qty. of packs per order	10
Package dimensions [mm]	150X060X048
Volume [cm³]	43.2
Bar code [EAN13]	8013975042281
HS Code	85365080
Product designation	Illuminated selector switch actuators - 2 position
Product type designation	8LM2TSL1
Colour	Red
Type of positions	Selector switch
Material	Aluminium and zinc alloy
IEC degree of protection	IP40
Max power	1.2
Operating force	0.8kg/1.7Ib
Mechanical life	300000
Mounting adapter	LM2TAU120
UL degree of protection	Type 1, 2, 3R, 4, 4X, 12, 12K
min [°C]	-40
max [°C]	+70
ETIM 8.0	EC000222 - Front element for selector switch

Frequently Asked Questions

What is the Lovato 8LM2TSL1204 used for?

The Lovato 8LM2TSL1204 is an illuminated selector switch actuator used for manual control and visual indication in industrial automation and electrical control panels.

How many positions does this selector switch have?

The actuator has two positions: 0-1, providing simple selector control operation.

What colour is the illuminated selector?

The 8LM2TSL1204 features a red illuminated selector knob for clear operator indication.

What mounting size is required?

The actuator is designed for standard Ø22 mm panel mounting applications.

What protection rating does this selector actuator provide?

The actuator provides IP65 front protection when installed correctly, making it suitable for industrial control applications.

Trusted by Industrial Automation Professionals

Lovato Electric selector switches are widely used in industrial automation and electrical control applications where reliable operator control, clear indication and long service life are required.

Illumination	Illuminated
Product Series	Lovato 8LM Metal
Mounting Diameter	22 mm
Device Type	Selector Switch
IP Rating	IP40
Weight [g]	25
Qty. per package	10
Multiple qty. of packs per order	10
Package dimensions [mm]	150X060X048
Volume [cm³]	43.2
Bar code [EAN13]	8013975042281
HS Code	85365080
Product designation	Illuminated selector switch actuators - 2 position
Product type designation	8LM2TSL1
Colour	Red
Type of positions	Selector switch
Material	Aluminium and zinc alloy
IEC degree of protection	IP40
Max power	1.2
Operating force	0.8kg/1.7Ib
Mechanical life	300000
Mounting adapter	LM2TAU120
UL degree of protection	Type 1, 2, 3R, 4, 4X, 12, 12K
min [°C]	-40
max [°C]	+70
ETIM 8.0	EC000222 - Front element for selector switch
Colour	Red
