Lovato Electric 8LM2TSL1208 electrical installation component for professional commercial and industrial assemblies, suitable for maintenance, replacement and panel building applications.
Original price was: £18.16.£12.71Current price is: £12.71.
The Lovato 8LM2TSL1208 is a dependable illuminated selector switch actuator designed for industrial control panels, automation equipment and machine operator interfaces. Part of the Lovato 8LM series metal selector switch range, this 22mm front element provides reliable manual switching control with clear white illuminated indication for improved operator visibility.
Featuring a robust aluminium and zinc alloy construction, the 8LM2TSL1208 is engineered for demanding industrial environments where durability, accurate switching and long operational life are required. The actuator provides a two-position 0-1 maintained selector function and is designed for use with compatible Lovato LM2T series contact blocks and accessories.
With its compact 22mm panel mounting format, metal construction and illuminated white selector knob, the Lovato 8LM2TSL1208 is suitable for electrical cabinets, machine control stations and automation systems requiring clear operator interaction and dependable performance.
Selector switches are essential components in industrial control systems, allowing operators to select machine functions, operating modes and control states. The Lovato 8LM2TSL1208 combines illuminated feedback with durable mechanical construction to provide a clear and reliable operator interface.
Its compact design and compatibility with Lovato LM2T components make it an excellent choice for machine builders, OEM control panels and industrial automation applications where dependable switching performance is required.
| IP Rating | IP40 |
|---|---|
| Weight [g] | 25 |
| Qty. per package | 10 |
| Multiple qty. of packs per order | 10 |
| Package dimensions [mm] | 150X060X048 |
| Volume [cm³] | 43.2 |
| Bar code [EAN13] | 8013975042311 |
| HS Code | 85365080 |
| Product designation | Illuminated selector switch actuators - 2 position |
| Product type designation | 8LM2TSL1 |
| Colour | White |
| Type of positions | Selector switch |
| Material | Aluminium and zinc alloy |
| IEC degree of protection | IP40 |
| Max power | 1.2 |
| Operating force | 0.8kg/1.7Ib |
| Mechanical life | 300000 |
| Mounting adapter | LM2TAU120 |
| UL degree of protection | Type 1, 2, 3R, 4, 4X, 12, 12K |
| min [°C] | -40 |
| max [°C] | +70 |
| ETIM 8.0 | EC000222 - Front element for selector switch |
The Lovato 8LM2TSL1208 is an illuminated selector switch actuator used for operator control functions in industrial automation panels and machinery.
The selector actuator provides two maintained positions with a 0-1 selector function.
The 8LM2TSL1208 is designed for standard 22mm panel mounting applications.
This model features a white illuminated selector knob for clear visual indication.
The actuator is designed for industrial control panels, machinery and automation systems requiring reliable operator switching.
Lovato Electric selector switches are widely used in industrial automation and machinery applications where dependable control, clear indication and long service life are essential.{ "@context": "https://schema.org/", "@type": "Product", "name": "Lovato 8LM2TSL1208 Illuminated Selector Switch Actuator 22mm White", "sku": "8LM2TSL1208", "mpn": "8LM2TSL1208", "brand": { "@type": "Brand", "name": "Lovato Electric" }, "category": "Selector Switches", "description": "Lovato 8LM2TSL1208 illuminated selector switch actuator, 22mm metal two position 0-1 white selector for industrial control panels and automation systems.", "additionalProperty": [ { "@type": "PropertyValue", "name": "Mounting size", "value": "22mm" }, { "@type": "PropertyValue", "name": "Positions", "value": "2" }, { "@type": "PropertyValue", "name": "Colour", "value": "White" }, { "@type": "PropertyValue", "name": "Protection rating", "value": "IP40" }, { "@type": "PropertyValue", "name": "Mechanical life", "value": "300000 cycles" } ] } { "@context": "https://schema.org", "@type": "FAQPage", "inLanguage": "en-GB", "mainEntity": [ { "@type": "Question", "name": "What is the Lovato 8LM2TSL1208 used for?", "acceptedAnswer": { "@type": "Answer", "text": "The Lovato 8LM2TSL1208 is an illuminated selector switch actuator used for operator control functions in industrial automation panels and machinery." } }, { "@type": "Question", "name": "How many positions does this selector switch have?", "acceptedAnswer": { "@type": "Answer", "text": "The selector actuator provides two maintained positions with a 0-1 selector function." } }, { "@type": "Question", "name": "What mounting size is required?", "acceptedAnswer": { "@type": "Answer", "text": "The 8LM2TSL1208 is designed for standard 22mm panel mounting applications." } }, { "@type": "Question", "name": "What colour is the illuminated selector actuator?", "acceptedAnswer": { "@type": "Answer", "text": "This model features a white illuminated selector knob for clear visual indication." } }, { "@type": "Question", "name": "What environments is this selector switch suitable for?", "acceptedAnswer": { "@type": "Answer", "text": "The actuator is designed for industrial control panels, machinery and automation systems requiring reliable operator switching." } } ] }
