Why Choose the Pizzato E21PDBL9AAAB Double Pushbutton?
The Pizzato E21PDBL9AAAB is a robust double projecting pushbutton actuator designed for machine control panels, operator stations and industrial automation systems. As part of the Pizzato Elettrica EROUND E2 PD series, it combines two momentary control buttons with a central backlit cap in one compact panel-mounted device.
This actuator features black upper and lower projecting buttons with directional arrow markings, making it suitable for up/down movement commands and similar paired control functions. The white central cap can be illuminated when the actuator is combined with a compatible Pizzato LED unit, while the satin-chrome bezel provides a durable, professional appearance.
With IP67 and IP69K protection, the E21PDBL9AAAB is designed for demanding industrial environments, including equipment exposed to dust, water immersion and high-pressure hot-water cleaning. Its modular construction accepts compatible EROUND mounting adapters, contact blocks and LED units, allowing the required electrical configuration to be assembled for each application.
Key Advantages
- Two projecting momentary buttons housed in one compact actuator.
- Clear up and down arrow markings support intuitive directional control.
- White central cap supports backlighting with a compatible Pizzato LED unit.
- IP67 and IP69K protection for harsh and washdown environments.
- High mechanical endurance for frequent industrial operation.
- Modular EROUND design supports flexible contact and illumination configurations.
Key Features
- Pizzato EROUND E2 PD series double pushbutton actuator.
- Upper and lower projecting black buttons.
- Upper button marked with an up arrow.
- Lower button marked with a down arrow.
- Flush white central cap designed for illumination.
- Satin-chrome bezel.
- Spring-return momentary actuation.
- Compatible with modular Pizzato EROUND contact blocks and LED units.
Reliable Directional Control for Industrial Machinery
Double pushbuttons combine two related operator commands within a single panel position. The up and down arrow markings on the Pizzato E21PDBL9AAAB make machine movements easy to identify while reducing the panel space required compared with two separate actuators.
The actuator is supplied as part of a modular control system and can be paired with suitable Pizzato mounting hardware, contact blocks and an LED unit. This enables designers to choose the required normally open or normally closed contact arrangement and add central-cap illumination for status indication.
Typical Applications
- Up and down control of hoists, lifts and lifting equipment.
- Forward and reverse control of industrial machinery.
- Positioning commands for conveyors and material-handling systems.
- Opening and closing control for doors, gates and actuators.
- Machine-tool and production-line operator panels.
- Washdown equipment and demanding industrial environments.
