Pfannenberg 32035804000 IS-mC1 ATEX Explosion-Protected Amber LED Sounder Beacon 24V DC
The Pfannenberg 32035804000 is an IS-mC1 intrinsically safe ATEX LED sounder beacon designed for combined visual and audible alarm signalling in hazardous industrial environments. Featuring an amber LED flashing light, integrated electronic sounder, 24 V DC operation, and compatibility with ATEX Zones 0, 1, and 2, this compact signalling device provides reliable warning indication where explosive atmospheres may occur.
Designed for industrial safety applications, the Pfannenberg IS-mC1 combines low power consumption, compact installation dimensions, 49 selectable alarm tones, and intrinsically safe operation through approved zener barriers or galvanic isolators. The unit provides both visual and acoustic alarm functions in a single compact housing.
Key Features
- Intrinsically safe ATEX LED sounder beacon for hazardous areas
- Manufacturer part number: 32035804000
- Series: Pfannenberg IS-mC1
- Amber LED flashing light output
- Integrated electronic sounder
- 24 V DC rated operating voltage
- Operating voltage range: 16–28 V DC
- Suitable for ATEX Zones 0, 1 and 2
- 49 selectable alarm tones
- Sound output up to 102 dB(A)
- Adjustable volume level
- Compact 88 mm diameter design
- IP65 protection rating
Applications
The Pfannenberg 32035804000 IS-mC1 is suitable for hazardous-area alarm applications including chemical processing plants, oil and gas facilities, fire alarm systems, process industries, manufacturing environments, and industrial safety installations requiring combined audible and visual signalling.
Why Choose Pfannenberg 32035804000?
The Pfannenberg IS-mC1 provides an efficient combined signalling solution by integrating LED visual indication and a high-output electronic sounder in one compact intrinsically safe device. Its low power consumption, selectable tones, and ATEX compatibility make it suitable for safety-critical environments requiring dependable alarm notification.
