Pfannenberg 23353635055 PA L 5 LED Sounder Beacon Combination
The Pfannenberg 23353635055 is a PATROL Series PA L 5
combined LED sounder beacon designed for industrial alarm, warning, and safety
applications. This compact signaling device combines a high-output electronic sounder
with a red LED flashing beacon to provide dependable audible and visual indication in
demanding industrial environments. The unit features a grey housing with red lens and
operates from a 12–48 V DC supply range.
The PA L 5 delivers powerful acoustic signaling with up to 107 dB(A)
sound output and includes 80 stored alarm tones for flexible warning applications.
The LED flashing light and sounder can operate independently, while IP66 protection,
IK08 impact resistance, and NEMA Type 4/4X suitability provide reliable performance in
industrial environments.
Key Features
- Manufacturer: Pfannenberg
- Model / SKU: 23353635055
- Series: PATROL PA L 5
- Combined LED flashing beacon and electronic sounder
- Supply voltage: 12–48 V DC
- Grey housing with red LED lens
- Maximum sound pressure level: 107 dB(A)
- 80 stored alarm tones
- 64 selectable basic tones
- Additional externally selectable tones
- Independent operation of sounder and LED light
- LED flashing technology for efficient long-life operation
- IP66 ingress protection
- IK08 impact-resistant housing
- NEMA Type 4/4X protection
- Operating temperature range: -40 °C to +55 °C
Applications
The Pfannenberg 23353635055 PA L 5 is suitable for factory automation, machinery
safety systems, production equipment, process control installations, emergency warning
systems, and industrial facilities requiring reliable audible and visual signaling.
Why Choose Pfannenberg 23353635055?
The PA L 5 combines efficient LED visual indication with powerful acoustic signaling
in a rugged industrial enclosure. Its wide voltage range, selectable alarm tones,
excellent sound penetration, and environmental protection make it suitable for
demanding industrial warning applications.
