Pfannenberg PYRA series PY X-M-05 10-57V DC AM RAL7035PY X-M-05 10-57V DC AM RAL7035
Pfannenberg PY X-M-05 10-57V DC AM RAL7035 PYRA xenon flashing signal light designed for reliable amber visual warning and industrial signalling applications.
SKU:21550814055MPN:21550814055
Price on applicationContact us for pricing and availability.
The Pfannenberg 21550814055 PY X-M-05 is a PYRA® series
high-performance xenon flashing light designed for industrial warning,
automation, and safety signaling applications. Featuring an amber lens,
grey RAL 7035 housing, and 24V AC/DC operation, this robust flashing beacon
provides a powerful 5 Joule xenon flash output for highly visible signaling
in demanding industrial environments.
Built with Pfannenberg's proven xenon technology, the PY X-M-05 offers
adjustable flash rates, synchronization capability for multiple connected
units, flexible mounting options, and IP66 protection. The impact-resistant
PC/ABS housing and wide operating temperature range make it suitable for
industrial and outdoor installations.
Product Features
Manufacturer: Pfannenberg
Part Number: 21550814055
Series: PYRA PY X-M-05
High-intensity xenon flashing technology
5 Joule flash energy output
Amber lens with grey RAL 7035 housing
24V AC/DC rated supply voltage
Supports 12V, 24V and 48V DC systems
Adjustable flash rates via DIP switch
Automatic synchronization for multiple flashing lights
Suitable for surface and panel mounting
IP66 protection rating
NEMA 4/4X protection
IK08 impact-resistant housing
Long service life with approximately 8 million flashes
Applications
The Pfannenberg 21550814055 PY X-M-05 is suitable for industrial automation,
machinery safety systems, manufacturing equipment, process plants, control
cabinets, warehouses, and warning installations requiring a highly visible
amber flashing signal.
Benefits
Powerful xenon flash technology for excellent visibility
Reliable operation in harsh industrial environments
Wide voltage compatibility for flexible system integration
Synchronization capability for coordinated warning systems
IP66 protection against dust and water ingress
Long operating life with consistent flash performance
Technical Specifications
Tick the specs you need, then view products that match.
Light Function
Xenon flash
Coil / Supply Voltage
12–24 V DC
Illumination
Illuminated
Product Series
Pfannenberg PYRA
Voltage
10–57 V DC
Product Type
Xenon Flashing Light
Series
PYRA PY X-M-05
Part Number
21550814055
Rated Voltage
12V / 24V / 48V DC, 24V AC
Operating Voltage Range
10-57V DC / 18-30V AC
Lens Colour
Amber
Housing Colour
Grey RAL 7035
Light Source
Xenon Flash Tube
Flash Energy
5 Joules
Flash Rate
1 Hz / Adjustable via DIP Switch
Maximum Visibility
Up to 173 m
Protection Rating
IP66
Impact Protection
IK08
Housing Material
PC / ABS Blend
Operating Temperature
-40°C to +55°C
Dimensions
114 x 154 x 124 mm
Weight
Approx. 0.4 kg
HS Code
85318070
IP Rating
IP66
Colour
Amber
Frequently Asked Questions
What is the Pfannenberg 21550814055?
The Pfannenberg 21550814055 is a PYRA PY X-M-05 xenon flashing light with
an amber lens, grey housing, and 24V AC/DC operation.
What voltage does the 21550814055 operate on?
This model supports 12V, 24V, and 48V DC supplies as well as 24V AC operation.
What is the flash energy of this beacon?
The PY X-M-05 provides a 5 Joule xenon flash output for high-visibility
industrial signaling.
Is the Pfannenberg 21550814055 suitable for outdoor use?
Yes. The IP66-rated enclosure, NEMA 4/4X protection, and wide temperature
range make it suitable for demanding industrial environments.
Light Function
Xenon flash
Coil / Supply Voltage
12–24 V DC
Illumination
Illuminated
Product Series
Pfannenberg PYRA
Voltage
10–57 V DC
Product Type
Xenon Flashing Light
Series
PYRA PY X-M-05
Part Number
21550814055
Rated Voltage
12V / 24V / 48V DC, 24V AC
Operating Voltage Range
10-57V DC / 18-30V AC
Lens Colour
Amber
Housing Colour
Grey RAL 7035
Light Source
Xenon Flash Tube
Flash Energy
5 Joules
Flash Rate
1 Hz / Adjustable via DIP Switch
Maximum Visibility
Up to 173 m
Protection Rating
IP66
Impact Protection
IK08
Housing Material
PC / ABS Blend
Operating Temperature
-40°C to +55°C
Dimensions
114 x 154 x 124 mm
Weight
Approx. 0.4 kg
HS Code
85318070
IP Rating
IP66
Colour
Amber
