Finder 39.01.0.024.0060 is a 6.2 mm MasterBASIC electromechanical relay interface module with a 24 V AC/DC input, one 6 A changeover contact and push-in terminals.
Why Choose the Finder 39.01.0.024.0060 MasterBASIC Relay Interface Module?
The Finder 39.01.0.024.0060 is a slim and dependable electromechanical relay interface module designed to isolate and interface electronic controllers with industrial field equipment. As part of the Finder Series 39 MasterINTERFACE range, this MasterBASIC module provides reliable switching for PLC, automation and general control-panel applications.
The module incorporates coil-status indication and a protection circuit to simplify commissioning and operational monitoring. Its replaceable electromechanical relay is secured by a plastic retaining and release clip, while optional jumper links permit common connection of the A1, A2 and 11 terminals across multiple modules.
With a 24 V AC/DC input and one changeover contact rated at 6 A and 250 V AC, the 39.01.0.024.0060 is suitable for controlling compatible contactors, solenoid valves, indicators and other electrical loads. Its push-in terminals and compact 6.2 mm width support rapid wiring and efficient use of control-panel space.
Key Advantages
Slim electromechanical relay interface module for PLC systems.
6 A changeover contact supports flexible load switching.
24 V AC/DC input suitable for common industrial control circuits.
Integral coil-status indication and protection circuit.
Push-in terminals enable quick and secure conductor installation.
Replaceable relay simplifies servicing and maintenance.
Key Features
Finder Series 39 MasterINTERFACE MasterBASIC.
Single changeover contact.
6 A nominal contact current.
24 V AC/DC nominal input voltage.
AgNi contact material.
Optional jumper links for common terminal connections.
Space-saving 6.2 mm-wide housing.
Direct mounting on a 35 mm DIN rail.
Reliable Electromechanical Interfacing for Automation Systems
Electromechanical relay interface modules enable low-voltage controllers to switch and isolate compatible AC or DC field loads. A changeover contact provides normally open and normally closed switching paths, supporting a broad range of industrial control functions.
The Finder Series 39 MasterBASIC range is designed for general interface applications between auxiliary contacts, sensors, PLCs, controllers, relays and solenoids. Its slim construction, push-in wiring and jumper-link compatibility support efficient installation within modern automation panels.
Typical Applications
PLC input and output interfaces.
Industrial automation control panels.
Packaging and labelling machinery.
Material-handling and warehouse systems.
Solenoid valve and contactor control.
Electrical distribution and process-control panels.
Technical Specifications
Tick the specs you need, then view products that match.
Terminal Type
Push-in
Load Voltage
400 V AC
Mounting Type
DIN rail
Switching Current (A)
6 A
Manufacturer
Finder
Series
Series 39 MasterINTERFACE
Range
MasterBASIC
Model
39.01.0.024.0060
Product type
Electromechanical relay interface module
Contact configuration
1 changeover contact (SPDT)
Rated contact current
6 A
Maximum peak current
10 A
Rated switching voltage
250 V AC
Maximum switching voltage
400 V AC
Rated load AC1
1500 VA
Rated load AC15 at 230 V AC
300 VA
Single-phase motor rating at 230 V AC
0.185 kW
DC1 breaking capacity at 24 / 110 / 220 V
6 / 0.2 / 0.12 A
Minimum switching load
500 mW at 12 V / 10 mA
Contact material
AgNi
Nominal input voltage
24 V AC/DC
Input operating range
19.2–26.4 V AC/DC
Holding voltage
0.6 UN
Must drop-out voltage
0.1 UN
Mechanical life
10,000,000 cycles
Electrical life at rated AC1 load
60,000 cycles
Operate / release time
5 / 6 ms
Coil-to-contact impulse withstand voltage
6 kV
Dielectric strength between open contacts
1000 V AC
Ambient temperature
−40 to +70 °C
Protection rating
IP20
Terminal type
Push-in terminals
Mounting type
35 mm DIN rail mounting
Width
6.2 mm
Contacts
1 C/O
IP Rating
IP20
Frequently Asked Questions
What is the Finder 39.01.0.024.0060 used for?
This electromechanical relay interface module isolates and interfaces PLCs or electronic controllers with compatible industrial field loads.
What contact configuration does this module provide?
The module provides one changeover contact rated at 6 A and 250 V AC.
What input voltage does the module require?
The Finder 39.01.0.024.0060 has a nominal 24 V AC/DC input with an operating range of 19.2–26.4 V AC/DC.
What type of terminals does this module use?
This MasterBASIC module uses push-in terminals for quick and secure conductor installation.
How is the Finder 39.01.0.024.0060 installed?
The module mounts directly onto a standard 35 mm DIN rail and occupies 6.2 mm of panel width.
