4C.02.9.110.0050SPA Finder 2 CO Contacts DC Modular Interface Relay with Green LED + diode Indication

Q: What coil voltage does this relay require?

This relay module operates with a 110 V DC coil supply.

Q: What type of contact configuration does it have?

The relay uses a DPDT (Double Pole Double Throw) contact configuration with two changeover contacts.

Q: How is this relay installed?

The relay is installed on a standard 35 mm DIN rail inside electrical control cabinets and automation panels.

Finder 4C.02.9.110.0050SPA modular interface relay with two changeover contacts, 110 V DC coil, green LED indicator and diode suppression for PLC interface applications.

SKU: 4C.02.9.110.0050SPAAlt SKU: 4C0291100050SPAMPN: 4C.02.9.110.0050SPA

List Price £25.04 ex VAT

Your Price (ex VAT)

£25.04

Manufacturer Lead Time Standard Manufacturer Lead Time 6-8 Weeks, Call For Express Delivery Options

Get the best trade prices Trade exclusive

Create a trade account to unlock exclusive pricing, special offers and more.

Quantity:

SUBTOTAL (EX VAT) £25.04

Trade pricing is personalised to your account

Manufacturer Lead Time

£25.04

Why Choose the Finder 4C.02.9.110.0050SPA Interface Relay?

The Finder 4C.02.9.110.0050SPA is a compact and reliable DIN rail mounted interface relay module designed for industrial automation, PLC interfacing and electrical control panel applications. Part of the Finder 4C series relay interface modules, it provides dependable switching, electrical isolation and efficient signal control between automation systems and connected electrical loads.

Featuring a 110 V DC coil, DPDT (2 changeover) contact configuration and an 8 A switching capacity, the Finder 4C.02.9.110.0050SPA is suitable for industrial control systems requiring flexible switching capability and compact DIN rail installation.

The relay interface module includes integrated green LED status indication, diode coil suppression, screw terminal connections and a slim 15.8 mm housing for efficient use of cabinet space. Designed for standard 35 mm DIN rail mounting, it provides a practical solution for automation engineers, machine builders and control panel manufacturers.

Key Advantages

Compact DIN rail interface relay module for industrial automation systems.
110 V DC coil operation suitable for specialised control applications.
DPDT contact configuration provides flexible switching options.
8 A switching capacity for reliable industrial load control.
Space-saving 15.8 mm wide housing design.
Integrated LED indication and diode suppression module.

Key Features

Finder 4C series interface relay module.
110 V DC non-latching coil.
DPDT (2 CO) contact configuration.
8 A contact current rating.
250 V AC switching voltage.
110 V DC switching voltage.
35 mm DIN rail mounting according to EN 60715.
Screw terminal connections.
Silver alloy (AgNi) contact material.
Integrated green LED supply indication.
Diode coil suppression for improved protection.
Mechanical indicator and test button.

Reliable Switching for Industrial Automation

Interface relays such as the Finder 4C.02.9.110.0050SPA provide electrical separation between PLC outputs, electronic controllers and field devices. This improves system reliability while allowing safe switching of industrial loads.

The Finder 4C series is engineered for automation professionals requiring compact relay solutions with flexible contacts, simple installation and dependable performance in modern control panels. Its integrated indication and suppression features simplify commissioning and maintenance.

Typical Applications

PLC interface and industrial automation systems.
Electrical control panels and machine cabinets.
OEM machinery and production equipment.
Building automation systems.
Lighting and actuator control applications.
Industrial process control and monitoring systems.

Technical Specifications

Tick the specs you need, then view products that match.

Device Type	Interface Relay
Terminal Type	Screw
Load Voltage	400 V AC
Mounting Type	DIN rail
Switching Current (A)	10 A
Voltage	110 V
IP Rating	IP20
Coil / Supply Voltage	110 V DC
Contacts	2 C/O
Series	4C Series interface relays
Product type	Modular interface relay
Contact configuration	2 CO (DPDT)
Rated contact current	10 A
Rated switching voltage	250 V AC
Maximum switching voltage	400 V AC
Maximum switching load	approx. 2500 VA
Coil voltage	110 V DC
Indicator	Green LED
Coil protection	Integrated diode suppression
Contact material	Silver Nickel (AgNi)
Mounting	35 mm DIN rail
Terminal type	Screw terminals
Operating temperature	−40 °C to +70 °C
Protection rating	IP20
HS Code	85364900

Frequently Asked Questions

What is the Finder 4C.02.9.110.0050SPA used for?

The Finder 4C.02.9.110.0050SPA is an interface relay module used for switching and isolating electrical loads in industrial automation and control systems.

What coil voltage does this relay require?

This relay module operates with a 110 V DC coil supply.

What type of contact configuration does it have?

The relay uses a DPDT (Double Pole Double Throw) contact configuration with two changeover contacts.

What is the maximum switching current?

The Finder 4C.02.9.110.0050SPA supports a maximum switching current of 8 A.

How is this relay installed?

The relay is installed on a standard 35 mm DIN rail inside electrical control cabinets and automation panels.

Trusted for Industrial Control Applications

Finder 4C series relay interface modules are widely used by automation professionals and control panel builders for reliable signal switching, electrical isolation and efficient industrial system integration.

Device Type	Interface Relay
Terminal Type	Screw
Load Voltage	400 V AC
Mounting Type	DIN rail
Switching Current (A)	10 A
Voltage	110 V
IP Rating	IP20
Series	4C Series interface relays
Product type	Modular interface relay
Contact configuration	2 CO (DPDT)
Rated contact current	10 A
Rated switching voltage	250 V AC
Maximum switching voltage	400 V AC
Maximum switching load	approx. 2500 VA
Coil voltage	110 V DC
Indicator	Green LED
Coil protection	Integrated diode suppression
Contact material	Silver Nickel (AgNi)
Mounting	35 mm DIN rail
Terminal type	Screw terminals
Operating temperature	−40 °C to +70 °C
Protection rating	IP20
HS Code	85364900
Coil / Supply Voltage	110 V DC
Contacts	2 C/O
