Why Choose the Finder 4C.52.9.024.0050SPA Interface Relay?
The Finder 4C.52.9.024.0050SPA is a compact and reliable DIN rail mounted interface relay module designed for industrial automation, PLC interfacing and electrical control panel applications. Part of the Finder 4C.52 series relay interface modules, it provides dependable switching, electrical isolation and efficient signal control between automation systems and connected electrical loads.
Featuring a 24 V DC coil, DPDT (2 changeover) contact configuration and an 8 A switching capacity, the Finder 4C.52.9.024.0050SPA is suitable for industrial control systems requiring flexible switching capability, compact installation and reliable long-term operation.
The relay interface module includes spring clamp terminals, integrated LED indication, coil protection, mechanical indicator and test button functions. Its slim 15.8 mm housing allows efficient use of cabinet space while maintaining fast and secure wiring on standard 35 mm DIN rails.
Key Advantages
- Compact DIN rail interface relay module for industrial automation systems.
- 24 V DC coil operation compatible with PLC and control applications.
- DPDT contact configuration provides flexible switching options.
- 8 A switching capacity for reliable industrial load control.
- Space-saving 15.8 mm wide housing design.
- Integrated LED indication and coil protection.
Key Features
- Finder 4C.52 series interface relay module.
- 24 V DC non-latching coil.
- DPDT (2 CO) contact configuration.
- 8 A contact current rating.
- 8 A at 250 V AC switching capability.
- 8 A at 30 V DC switching capability.
- 35 mm DIN rail mounting according to EN 60715.
- Spring clamp terminal connections.
- Silver alloy contact material.
- Integrated LED supply indication.
- Mechanical indicator and lockable test button.
Reliable Switching for Industrial Automation
Interface relays such as the Finder 4C.52.9.024.0050SPA provide electrical separation between PLC outputs, electronic controllers and field devices. This improves system reliability while allowing safe switching of industrial loads.
The Finder 4C.52 series is engineered for automation professionals requiring compact relay solutions with fast wiring, flexible contacts and dependable performance in modern control panels. The spring clamp terminal design supports efficient installation while maintaining secure electrical connections.
Typical Applications
- PLC interface and industrial automation systems.
- Electrical control panels and machine cabinets.
- OEM machinery and production equipment.
- Building automation systems.
- Lighting and actuator control applications.
- Industrial process control and monitoring systems.
