Why Choose the Finder 94.03SPA 11-Pin Relay Socket?
The Finder 94.03SPA is a durable 11-pin relay socket with screw terminals, designed for industrial automation, electrical control panels and general-purpose relay installations. Part of the established Finder 94 Series, this socket provides a secure electrical and mechanical connection for compatible Finder 55.33 relays, helping simplify control panel wiring, relay installation and ongoing maintenance.
With a 10 A nominal current rating and 250 V AC rated voltage, the Finder 94.03SPA is suitable for a wide range of industrial relay interface applications. Its 11-pin configuration accommodates the three changeover contact arrangement of a compatible Finder 55.33 relay, making it useful for control circuits requiring multiple independently switched contacts.
Designed for 35 mm DIN rail or panel mounting, the socket features reliable screw-terminal connections and a plastic retaining and release clip supplied as part of the SPA configuration. The clip holds the relay securely in position while allowing straightforward removal and replacement without disturbing permanent field wiring. Its robust construction and operating temperature range of -40 to +70 °C make it a practical choice for industrial panel builders, automation engineers and maintenance technicians.
Key Advantages
- 11-pin relay socket specifically designed for compatible Finder 55.33 general-purpose relays.
- 10 A rated current for suitable industrial relay connections.
- 250 V AC rated voltage for electrical control and switching applications.
- Three changeover contact compatibility when fitted with a Finder 55.33 relay.
- Screw-terminal connections provide secure and dependable field wiring.
- DIN rail or panel mounting offers flexibility during electrical cabinet installation.
- Plastic retaining and release clip included for secure relay positioning.
- Plug-in relay arrangement allows relay replacement without disconnecting socket wiring.
- -40 to +70 °C operating temperature range supports demanding industrial environments.
- 6-way jumper link compatibility helps simplify common wiring connections across adjacent sockets.
- Suitable for industrial automation, machine control and electrical panel manufacturing.
- Established Finder 94 Series design supports maintenance of existing relay installations.
Key Features
- Finder 94 Series relay socket for industrial control applications.
- 11-pin socket configuration for compatible three-pole changeover relays.
- 10 A nominal current rating.
- 250 V AC nominal voltage rating.
- Screw terminals with box-clamp connections.
- 35 mm DIN rail mounting in accordance with EN 60715.
- Panel mounting capability for alternative installation arrangements.
- Compatible with Finder 55.33 relays.
- Plastic retaining and release clip supplied with the SPA version.
- Finder 094.91.3 retaining clip included in the socket configuration.
- Finder 094.06 6-way jumper link compatibility.
- Finder 094.00.4 identification tag compatibility.
- -40 to +70 °C ambient operating temperature range.
- Plug-in relay connection supports convenient servicing and replacement.
- Blue insulating housing for identification within control assemblies.
- Suitable for compatible relay assemblies with three changeover contacts.
Technical Specifications
- Manufacturer: Finder
- Series: 94 Series
- Model: 94.03SPA
- Base socket type: 94.03
- Product type: Industrial plug-in relay socket
- Socket configuration: 11-pin
- Number of socket positions: 11
- Rated current: 10 A
- Rated voltage: 250 V AC
- Terminal type: Screw terminals
- Terminal construction: Box-clamp screw terminals
- Mounting type: DIN rail or panel mounting
- DIN rail size: 35 mm
- DIN rail standard: EN 60715
- Compatible relay: Finder 55.33
- Associated timer relay: Finder 85.03, subject to configuration compatibility
- Compatible relay contact arrangement: 3 changeover contacts (3 CO)
- Ambient operating temperature: -40 to +70 °C
- Terminal tightening torque: 0.5 Nm
- Maximum solid conductor capacity: 1 × 6 mm² or 2 × 2.5 mm²
- Maximum flexible conductor capacity: 1 × 4 mm² or 2 × 2.5 mm²
- Housing colour: Blue
- Relay retention: Plastic retaining and release clip
- Included retaining clip: Finder 094.91.3
- Compatible jumper link: Finder 094.06, 6-way
- Compatible identification tag: Finder 094.00.4
- Country of origin: Italy
- EAN: 8012823283746
- RoHS compliance: RoHS compliant
Reliable Three-Changeover Relay Connections for Industrial Control
The Finder 94.03SPA relay socket provides a dependable connection between compatible plug-in relays and industrial electrical wiring. Designed for the Finder 55.33 relay, its 11-pin arrangement accommodates three changeover contact circuits and the relay coil connections. This makes it particularly useful where a single relay must control multiple electrical signals or switching functions.
When a compatible Finder 55.33 three-pole changeover relay is installed, each contact set provides a common, normally open and normally closed connection. These contacts can be used for control circuit interlocking, equipment status signalling, auxiliary switching and other applications requiring multiple relay outputs. The actual permissible switching load must be determined from the installed relay's electrical ratings and the characteristics of the connected load.
The socket's box-clamp screw terminals provide secure conductor termination, while its 35 mm DIN rail and panel mounting options give installers flexibility when designing electrical control cabinets. The SPA designation identifies the version supplied with a plastic retaining and release clip, allowing the relay to be secured firmly during operation and removed conveniently during maintenance.
For installations containing several relay sockets, the compatible Finder 094.06 6-way jumper link can simplify common electrical connections where the wiring arrangement permits. The optional identification tag also helps technicians label relay circuits clearly, supporting efficient commissioning, fault finding and future maintenance.
Typical Applications
- Industrial automation and machine control systems.
- Electrical control cabinets and distribution panels.
- PLC interface and auxiliary relay circuits.
- Three-changeover relay switching applications.
- Industrial process control and instrumentation.
- Conveyor and material handling equipment.
- Manufacturing and production line machinery.
- Motor control and auxiliary signalling circuits.
- Building management and electrical control systems.
- Equipment status monitoring and alarm circuits.
- OEM electrical panel manufacturing.
- Maintenance and replacement of Finder 55.33 relay socket assemblies.
