Why Choose the Finder 95.85.30SMA Relay Socket?
The Finder 95.85.30SMA is a black industrial relay socket with box-clamp screw terminals, designed for compatible Finder 40 Series plug-in relays. Part of the Finder 95 Series, it provides a practical connection interface for electrical control panels, industrial automation systems and auxiliary switching applications.
The socket supports compatible Finder 40.51, 40.52 and 40.61 relays, providing a convenient solution for single- and double-changeover relay applications. Its 35 mm DIN rail or panel mounting arrangement offers flexibility when assembling or maintaining industrial control cabinets.
The SMA configuration includes a metal retaining clip, helping secure the installed relay against accidental displacement. With 10 A / 250 V socket ratings, an IP20 protection category and compatibility with selected Finder accessories, the 95.85.30SMA is suitable for professional electrical panel installations.
Key Advantages
- Finder 40 Series compatibility: Designed for selected Finder 40.51, 40.52 and 40.61 relays.
- Box-clamp screw terminals: Provide secure conductor termination for industrial control wiring.
- Metal retaining clip: The SMA configuration includes a clip to help secure the installed relay.
- Black housing: Provides a distinct colour option for organised control panel assemblies.
- 10 A socket rating: Supports compatible switching circuits within the applicable relay and socket limits.
- 250 V rated voltage: Suitable for appropriately rated electrical control applications.
- DIN rail or panel mounting: Offers flexibility for different electrical enclosure layouts.
- Plug-in relay replacement: Allows the relay to be removed without disconnecting the socket's fixed wiring.
- Compact construction: Suitable for grouped relay installations in control cabinets.
- Optional indication and suppression: Supports selected Finder 99.80 Series modules.
- Jumper link compatibility: Supports suitable common-potential connections between adjacent sockets.
- IP20 protection: Intended for installation within appropriately protected electrical enclosures.
Key Features
- Finder 95 Series industrial relay socket.
- Model: 95.85.30SMA.
- Black housing configuration.
- Compatible with selected Finder 40.51, 40.52 and 40.61 relays.
- 8-position relay connection interface.
- Supports compatible single- and double-changeover relay arrangements.
- Box-clamp screw terminals.
- 10 A / 250 V rated socket values.
- 35 mm DIN rail or panel mounting.
- Metal retaining clip supplied with the SMA configuration.
- 6 kV impulse withstand voltage between coil and contacts.
- IP20 protection category.
- -40 to +70 °C ambient temperature range.
- 0.5 Nm terminal tightening torque.
- 7 mm conductor stripping length.
- Compatible with selected Finder 99.80 Series indication and suppression modules.
- Compatible with the black Finder 095.08.0 eight-way jumper link.
Technical Specifications
- Manufacturer: Finder
- Series: 95 Series
- Product code: 95.85.30SMA
- Base socket model: 95.85.30
- Product type: Industrial relay socket
- Compatible relay family: Finder 40 Series
- Compatible relay types: Finder 40.51, 40.52 and 40.61
- Relay connection positions: 8
- Supported contact arrangements: According to compatible relay selection
- Rated socket current: 10 A
- Rated socket voltage: 250 V
- Terminal technology: Box-clamp screw terminals
- Mounting method: DIN rail or panel mounting
- DIN rail size: 35 mm
- DIN rail standard: EN 60715
- Impulse withstand voltage between coil and contacts: 6 kV (1.2/50 µs)
- Protection category: IP20
- Ambient operating temperature: -40 to +70 °C
- Terminal screw tightening torque: 0.5 Nm
- Conductor stripping length: 7 mm
- Maximum solid conductor size: 1 × 6 mm² or 2 × 2.5 mm²
- Maximum stranded conductor size: 1 × 4 mm² or 2 × 2.5 mm²
- Included retaining clip: Finder 095.71 metal retaining clip
- Optional plastic retaining and release clip: Finder 095.91.30
- Compatible jumper link: Finder 095.08.0, black, eight-way
- Compatible indication and suppression modules: Finder 99.80 Series
- Identification tag: Finder 095.80.3
- Housing colour: Black
- Product category: Relay Sockets and Accessories
Secure Plug-In Relay Connections for Industrial Control Systems
The Finder 95.85.30SMA provides the electrical connection interface between a compatible Finder 40 Series relay and the external control circuit. Its socket terminals connect the relay coil and switching contacts to the fixed panel wiring, while the plug-in arrangement allows the relay to be installed or removed independently of those connections.
The socket is designed for compatible Finder 40.51, 40.52 and 40.61 relays. The installed relay determines the contact arrangement, coil voltage and permissible switching capacity. The socket's rated values must not be interpreted as overriding the electrical limits of the selected relay.
The box-clamp screw terminals provide conventional conductor connections, while the included 095.71 metal retaining clip helps secure the relay in position. The socket can be installed on a standard 35 mm DIN rail or mounted directly onto a suitable panel.
For installations requiring additional functionality, compatible Finder 99.80 Series modules can provide indication or EMC suppression, depending on the selected accessory. The black Finder 095.08.0 eight-way jumper link can simplify common-potential wiring across compatible socket assemblies.
Typical Applications
- Industrial automation control panels.
- Finder 40 Series relay installations.
- Machinery and equipment control systems.
- PLC interface and auxiliary switching circuits.
- Industrial process automation.
- Electrical distribution and switchgear control cabinets.
- Motor control auxiliary circuits.
- Industrial signalling and interlocking systems.
- Building automation and HVAC control systems.
- OEM machinery and equipment manufacturing.
- Lighting and equipment control circuits.
- Control panel refurbishment and upgrades.
- Industrial relay maintenance and replacement.
- Electrical assemblies requiring black relay socket components.
