Why Choose the Finder 97.P2SMA Push-In Relay Socket?
The Finder 97.P2SMA is an industrial push-in relay socket with a metal retaining clip, designed for compatible Finder 46.52 and 46.52T miniature industrial relays. Part of the Finder 97 Series, this blue relay socket provides a secure connection interface for electrical control panels, industrial automation systems and machinery control applications.
Featuring an 8 A nominal current rating and 250 V AC rated voltage, the Finder 97.P2SMA supports suitable relay control and auxiliary switching circuits. Its screwless push-in spring terminals allow appropriately prepared conductors to be connected without conventional terminal screw tightening, helping simplify installation and reduce repetitive wiring operations.
The socket is designed for 35 mm DIN rail or panel mounting and is supplied with a Finder 097.71 metal retaining clip. The clip helps keep the installed relay securely positioned, while the plug-in arrangement allows the relay to be replaced without disturbing permanent field wiring.
With support for selected Finder 99.02 coil indication and EMC suppression modules, Finder 86.30 timer modules and compatible jumper links, the Finder 97.P2SMA offers a flexible solution for control panel manufacturers, automation engineers and industrial maintenance professionals.
Key Advantages
- Finder 97 Series relay socket designed for compatible Finder 46.52 relays.
- Push-in spring terminals simplify conductor installation.
- 8 A nominal current rating for suitable industrial control circuits.
- 250 V AC nominal voltage rating.
- Metal retaining clip included for secure relay positioning.
- 35 mm DIN rail mounting supports standard electrical cabinet installation.
- Panel mounting option provides additional installation flexibility.
- Two-changeover relay compatibility supports independent auxiliary switching functions.
- Plug-in relay arrangement enables convenient maintenance and replacement.
- Compatible indication and suppression accessories support additional control circuit functionality.
- Compatible timer modules allow suitable relay assemblies to incorporate timing functions.
- Jumper link compatibility simplifies common connections between appropriate socket assemblies.
Key Features
- Finder 97 Series industrial relay socket.
- Model 97.P2SMA.
- Push-in spring terminal connection system.
- Screwless conductor termination.
- 8 A rated current.
- 250 V AC rated voltage.
- Compatible with Finder 46.52 relays.
- Finder 46.52T compatibility for suitable relay configurations.
- Two-changeover contact arrangement with the installed compatible relay.
- 35 mm DIN rail mounting in accordance with EN 60715.
- Panel mounting capability.
- Finder 097.71 metal retaining clip supplied with the SMA configuration.
- Blue insulating housing.
- Compatible with selected Finder 99.02 indication and EMC suppression modules.
- Compatible with selected Finder 86.30 timer modules.
- Compatible with Finder 097.42 and 097.52 jumper links.
- Compatible with Finder 097.58 8-way jumper links.
- Identification and marking accessory compatibility for organised panel wiring.
Technical Specifications
- Manufacturer: Finder
- Series: 97 Series
- Model: 97.P2SMA
- Alternative part number formatting: 97.P2.SMA
- Base socket type: 97.P2
- Product type: Industrial plug-in relay socket
- Terminal type: Push-in spring terminals
- Connection method: Screwless push-in connection
- Rated current: 8 A
- Rated voltage: 250 V AC
- Mounting type: DIN rail or panel mounting
- DIN rail size: 35 mm
- DIN rail standard: EN 60715
- Compatible relay family: Finder 46 Series
- Compatible relay types: Finder 46.52 and suitable 46.52T configurations
- Compatible relay contact arrangement: 2 changeover contacts (2 CO)
- Housing colour: Blue
- Relay retention: Metal retaining clip
- Included retaining clip: Finder 097.71
- Maximum conductor capacity: 1 × 2.5 mm² or 2 × 1.5 mm², subject to conductor type and installation requirements
- Compatible coil indication and suppression accessories: Selected Finder 99.02 modules
- Compatible timer accessory: Finder 86.30, subject to relay and module compatibility
- Compatible 2-way jumper links: Finder 097.42 and 097.52
- Compatible 8-way jumper link: Finder 097.58
- Compatible identification tags: Finder 060.48
- Compatible marker tag holder: Finder 097.00
- Relay coil voltage: Determined by the installed compatible relay
- Relay supplied: No; compatible relay selected separately
- RoHS status: RoHS compliant
Efficient Push-In Relay Connections for Industrial Automation and Control Panels
The Finder 97.P2SMA relay socket provides a dependable electrical and mechanical interface for compatible Finder 46.52 relays. When fitted with a suitable two-changeover relay, the assembly can control two separate switching circuits through a common relay coil. This makes it useful for auxiliary control, status indication, electrical interlocking and machine control applications.
Each changeover contact provides common, normally open and normally closed connections. When the installed relay coil is energised, the contacts change state according to the relay's operating characteristics. The socket provides the permanent wiring interface, while the relay determines the coil voltage, contact operation and permissible switching load.
The push-in terminal system helps reduce installation time compared with conventional screw-terminal wiring. Suitable conductors can be connected using the spring terminal mechanism, making the socket particularly practical for repetitive control panel manufacturing. The conductor type, cross-sectional area and preparation must follow Finder's installation requirements.
The supplied Finder 097.71 metal retaining clip helps maintain secure relay positioning. During servicing, the compatible plug-in relay can be removed from the socket without disconnecting the permanent field wiring, provided the electrical circuit has first been safely isolated.
For additional functionality, selected Finder 99.02 indication and EMC suppression modules can provide coil status indication or electrical interference suppression. Compatible Finder 86.30 timing modules may also be used in suitable relay assemblies. Where several compatible sockets are installed together, jumper links can help distribute common electrical connections efficiently.
Typical Applications
- Industrial automation and machinery control systems.
- Electrical control cabinets and relay panels.
- PLC interface and auxiliary switching circuits.
- Two-changeover relay control applications.
- Manufacturing and production equipment.
- Conveyor and material handling systems.
- Industrial process control and instrumentation.
- Equipment status indication and monitoring.
- Electrical interlocking and control signalling.
- OEM control panel manufacturing and relay system maintenance.
