RSE2PN230AC IMO General Purpose Power Relay 2PCO, 10A, 230VAC, 1.5W

Q: What contact rating does the RSE2PN230AC have?

The relay provides a 10 A switching capability with a 2PCO changeover contact arrangement.

Q: What coil voltage does the RSE2PN230AC require?

The relay operates with a 230 V AC coil supply.

Q: What type of contacts does this relay provide?

The RSE2PN230AC uses 2PCO (DPDT) changeover contacts for flexible circuit switching.

Q: How is the RSE2PN230AC installed?

The relay is designed for plug-in socket mounting using compatible IMO relay bases.

IMO RSE2PN230AC general purpose power relay with 2PCO contacts, 10 A switching capacity and 230 V AC coil supply for industrial control applications.

SKU: RSE2PN230ACMPN: RSE2PN230AC

List Price £11.68 ex VAT

Your Price (ex VAT)

£11.68

Manufacturer Lead Time Please contact us for a delivery time before you order

Get the best trade prices Trade exclusive

Create a trade account to unlock exclusive pricing, special offers and more.

Quantity:

SUBTOTAL (EX VAT) £11.68

Trade pricing is personalised to your account

Manufacturer Lead Time

£11.68

Why Choose the IMO RSE2PN230AC General Purpose Power Relay?

The IMO RSE2PN230AC is a reliable general purpose electromechanical power relay designed for dependable switching of electrical loads in industrial automation, control panels and machinery applications. Part of the IMO RSE relay series, this plug-in relay provides robust switching performance with a compact design suitable for industrial control systems.

This relay features a 2PCO (DPDT) contact configuration with a 10 A switching capacity and a 230 V AC coil supply. Its plug-in format, LED indication and mechanical flag indicator allow easy installation, monitoring and maintenance in electrical control applications.

Designed for industrial reliability, the IMO RSE2PN230AC is suitable for switching control circuits, automation equipment and general-purpose electrical loads where dependable relay operation is required. Its industry-standard 8-pin round terminal design supports installation with compatible IMO relay sockets.

Key Advantages

Reliable general purpose power relay for industrial control applications.
10 A contact switching capability for a wide range of electrical loads.
230 V AC coil voltage for industrial control circuits.
2PCO changeover contacts provide flexible switching options.
Plug-in design simplifies replacement and maintenance.
LED and mechanical flag indication provide clear relay status monitoring.

Key Features

IMO RSE relay series.
10 A switching current rating.
230 V AC coil operation.
2PCO / DPDT contact arrangement.
8-pin plug-in relay format.
LED indication and mechanical flag indicator.
Compatible with IMO RSE relay sockets.
Suitable for industrial automation and control panels.

Reliable Switching for Industrial Control Systems

Electromechanical relays such as the IMO RSE2PN230AC provide a dependable interface between control systems and electrical loads. They allow low-power control signals to safely switch higher-power circuits, making them widely used throughout industrial automation and machinery applications.

The RSE relay series combines compact construction, plug-in installation and clear status indication to simplify panel design, commissioning and maintenance in industrial environments.

Typical Applications

Industrial control panels.
Automation and machine control systems.
Motor and actuator switching circuits.
PLC interface applications.
Electrical load switching.
General industrial relay replacement applications.

Technical Specifications

Tick the specs you need, then view products that match.

Device Type	Plug-in Relay
Mounting Type	Plug-in socket
Switching Current (A)	10 A
Coil / Supply Voltage	230 V AC
Contacts	4 C/O
HS Code	8536490099
Country of Manufacture	China
Manufacturer	IMO
Series	RSE
Model	RSE2PN230AC
Product type	General purpose power relay
Contact configuration	2PCO (DPDT)
Contact current	10 A
Coil voltage	230 V AC
Coil power	1.5 W
Relay type	Plug-in electromechanical relay
Number of pins	8
Indicator	LED and mechanical flag
Contact voltage AC	230 V AC
Contact voltage DC	28 V DC
Contact material	Silver Tin
Mounting type	Plug-in socket mounting
Terminal type	Quick connect
Dimensions	approx. 35 × 35 × 53 mm
Operating temperature	-40 to +55 °C

Frequently Asked Questions

What is the IMO RSE2PN230AC used for?

The RSE2PN230AC is a general purpose power relay used for switching electrical loads in industrial automation and control applications.

What contact rating does the RSE2PN230AC have?

The relay provides a 10 A switching capability with a 2PCO changeover contact arrangement.

What coil voltage does the RSE2PN230AC require?

The relay operates with a 230 V AC coil supply.

What type of contacts does this relay provide?

The RSE2PN230AC uses 2PCO (DPDT) changeover contacts for flexible circuit switching.

How is the RSE2PN230AC installed?

The relay is designed for plug-in socket mounting using compatible IMO relay bases.

Trusted by Industrial Automation Engineers

IMO RSE relays provide reliable switching solutions for industrial automation, control panels and machinery applications requiring dependable electrical control.

Device Type	Plug-in Relay
Mounting Type	Plug-in socket
Switching Current (A)	10 A
HS Code	8536490099
Country of Manufacture	China
Manufacturer	IMO
Series	RSE
Model	RSE2PN230AC
Product type	General purpose power relay
Contact configuration	2PCO (DPDT)
Contact current	10 A
Coil voltage	230 V AC
Coil power	1.5 W
Relay type	Plug-in electromechanical relay
Number of pins	8
Indicator	LED and mechanical flag
Contact voltage AC	230 V AC
Contact voltage DC	28 V DC
Contact material	Silver Tin
Mounting type	Plug-in socket mounting
Terminal type	Quick connect
Dimensions	approx. 35 × 35 × 53 mm
Operating temperature	-40 to +55 °C
Coil / Supply Voltage	230 V AC
Contacts	4 C/O
