Finder 12.22.0.024.0000 is a 24 V AC/DC two-channel digital weekly time switch with two 16 A changeover contacts, 30 memory locations and DIN rail mounting.
£130.07
The Finder 12.22.0.024.0000 is a versatile two-channel digital weekly time switch designed for automatic control of electrical loads according to programmed times and days. As part of the Finder 12 Series, it provides independent scheduled switching for lighting, heating, ventilation and other electrical equipment in residential, commercial and industrial installations.
This electronic time switch features two changeover contacts and weekly programming with up to 30 memory locations. Its LCD display provides clear programming and status information, while holiday programming, pulse programming, manual operation and automatic summer/winter time adjustment provide flexible control for a wide range of applications.
With a 24 V AC/DC supply and two 16 A changeover contacts, the 12.22.0.024.0000 is suited to control systems requiring two independently switched channels. Its compact 35.8 mm wide DIN rail format occupies two modular spaces and enables straightforward installation within electrical distribution boards and control panels.
Digital time switches such as the Finder 12.22.0.024.0000 automatically operate connected circuits according to stored weekly schedules. Its two independent channels allow separate loads to follow different switching programmes, providing efficient automated control without requiring continuous manual intervention.
The Finder 12.22 combines weekly scheduling with holiday and impulse programming, automatic summer/winter time adjustment and manual operation. These functions make it suitable for electrical installations where dependable recurring control of two separate circuits is required.
| Manufacturer | Finder |
|---|---|
| Series | 12 Series |
| Model | 12.22.0.024.0000 |
| Product type | Digital weekly time switch |
| Number of channels | 2 |
| Contact configuration | 2 changeover contacts |
| Nominal switching current | 16 A at 250 V AC |
| Supply voltage | 24 V AC/DC |
| AC supply frequency | 50 / 60 Hz |
| Programming type | Weekly |
| Memory locations | 30 |
| Minimum switching interval | 1 minute |
| Clock accuracy | 0.5 seconds/day |
| Power reserve | 6 years |
| Display | LCD |
| Operating temperature | -30 to +55 °C |
| Protection rating | IP20 |
| Electrical connection | Screw terminals |
| Mounting type | DIN rail |
| Width | 35.8 mm |
| Height | 60 mm |
| Depth | 90 mm |
| Modular width | 2 modules |
The Finder 12.22.0.024.0000 is a two-channel digital weekly time switch used to automatically control two electrical circuits according to programmed switching schedules.
The 12.22.0.024.0000 operates from a 24 V AC/DC supply.
The time switch has two channels with two changeover contacts, allowing two electrical loads or circuits to be controlled.
The time switch provides a nominal switching current of 16 A at 250 V AC.
The time switch provides weekly programming with 30 memory locations, together with holiday and impulse programmes, manual operation and automatic summer/winter time adjustment.
Finder 12 Series time switches provide dependable programmable control for lighting, building services and electrical equipment, combining accurate scheduling with flexible switching functions and compact DIN rail installation.{ "@context": "https://schema.org/", "@type": "Product", "name": "Finder 12.22.0.024.0000 Two-Channel Digital Weekly Time Switch 16 A 24 V AC/DC", "sku": "12.22.0.024.0000", "mpn": "12.22.0.024.0000", "brand": { "@type": "Brand", "name": "Finder" }, "category": "Digital Time Switches", "description": "Finder 12.22.0.024.0000 is a 24 V AC/DC two-channel digital weekly time switch with two 16 A changeover contacts, 30 memory locations and DIN rail mounting.", "additionalProperty": [ { "@type": "PropertyValue", "name": "Supply voltage", "value": "24 V AC/DC" }, { "@type": "PropertyValue", "name": "Number of channels", "value": "2" }, { "@type": "PropertyValue", "name": "Contact configuration", "value": "2 changeover contacts" }, { "@type": "PropertyValue", "name": "Nominal switching current", "value": "16 A at 250 V AC" }, { "@type": "PropertyValue", "name": "Protection rating", "value": "IP20" } ] } { "@context": "https://schema.org", "@type": "FAQPage", "inLanguage": "en-GB", "mainEntity": [ { "@type": "Question", "name": "What is the Finder 12.22.0.024.0000 used for?", "acceptedAnswer": { "@type": "Answer", "text": "The Finder 12.22.0.024.0000 is a two-channel digital weekly time switch used to automatically control two electrical circuits according to programmed switching schedules." } }, { "@type": "Question", "name": "What supply voltage does the Finder 12.22.0.024.0000 require?", "acceptedAnswer": { "@type": "Answer", "text": "The 12.22.0.024.0000 operates from a 24 V AC/DC supply." } }, { "@type": "Question", "name": "How many channels does the Finder 12.22.0.024.0000 have?", "acceptedAnswer": { "@type": "Answer", "text": "The time switch has two channels with two changeover contacts, allowing two electrical loads or circuits to be controlled." } }, { "@type": "Question", "name": "What is the contact rating of the Finder 12.22.0.024.0000?", "acceptedAnswer": { "@type": "Answer", "text": "The time switch provides a nominal switching current of 16 A at 250 V AC." } }, { "@type": "Question", "name": "What programming functions does the Finder 12.22.0.024.0000 provide?", "acceptedAnswer": { "@type": "Answer", "text": "The time switch provides weekly programming with 30 memory locations, together with holiday and impulse programmes, manual operation and automatic summer/winter time adjustment." } } ] }
