Why Choose the ABB CT-MVS.22P Multifunction Timer Relay?
The ABB CT-MVS.22P is a compact and versatile multifunction electronic timer relay designed for precise timing and switching control in industrial automation, electrical control and machine systems. As part of the ABB CT-S timer relay range, it provides 10 selectable timing functions, 10 time ranges and two changeover outputs for flexible control applications.
The CT-MVS.22P provides 10 timing functions with selectable ranges from 0.05 s to 300 h. Its voltage-related control input can be used to start, stop or pause timing, while the front-face operating controls provide precise adjustment of the selected timing range and delay.
With a rated control supply voltage of 24–48 V DC / 24–240 V AC and 2 C/O (SPDT) output contacts rated at 250 V / 4 A, the CT-MVS.22P provides flexible timing and switching control in industrial automation and control panels. Its compact 22.5 mm housing with maintenance-free Easy Connect push-in terminals is designed for straightforward DIN-rail installation.
Key Advantages
- Versatile multifunction timer relay for industrial automation applications.
- 10 selectable timing functions for flexible control sequences.
- 10 time ranges from 0.05 s to 300 h for precise timing adjustment.
- 24–48 V DC / 24–240 V AC rated control supply for versatile installation.
- 2 C/O (SPDT) output contacts rated at 250 V / 4 A.
- Voltage-related, non-floating control input for flexible timing control.
- Precise front-face adjustment of the selected timing range.
- Maintenance-free Easy Connect push-in terminals for fast installation.
Key Features
- ABB CT-S timer relay range.
- Multifunction electronic timer relay.
- 10 timing functions.
- 10 selectable time ranges from 0.05 s to 300 h.
- 2 C/O (SPDT) output contacts.
- 24–48 V DC / 24–240 V AC rated control supply.
- Voltage-related, non-floating control input.
- Front-face operating elements for precise timing adjustment.
- Maintenance-free Easy Connect Technology with push-in terminals.
- Two LEDs for clear operating status indication.
- Compact DIN-rail mounting design.
- Sealable transparent cover available as an accessory.
Flexible Timing Control for Industrial Automation
Multifunction timer relays such as the ABB CT-MVS.22P provide configurable timing sequences within electrical control and automation systems. By offering multiple timing functions and selectable time ranges, the relay can be configured for different switching, delay and pulse requirements without requiring separate timer relay types for each application.
The CT-MVS.22P combines flexible timing adjustment with two changeover outputs and a voltage-related control input that can support starting, stopping or pausing the timing sequence. Its compact DIN-rail format, front-face adjustment controls and maintenance-free push-in terminals allow straightforward integration into modern industrial control panels and automation systems.
Typical Applications
- Industrial automation and control panels.
- Machine control and sequencing systems.
- Motor control and switching applications.
- Conveyor and material handling equipment.
- Pumps, fans and ventilation systems.
- Production and process machinery.
- Control systems requiring configurable timing functions.
- Applications requiring adjustable delay, pulse or flashing sequences.
