Why Choose the Finder 13.72.8.230.B002 YESLY Bluetooth Multifunction Relay?
The Finder 13.72.8.230.B002 is a versatile 2-channel Bluetooth multifunction electronic relay designed for intelligent lighting control and building automation. Part of the Finder 13 Series YESLY smart home system, this anthracite grey actuator combines wireless connectivity, independent programmable outputs and conventional push-button control in a compact device suitable for compatible modular wall-switch systems.
Featuring 2 independent normally open contacts rated at 6 A and 230 V AC, the Finder 13.72 provides flexible control of lighting and other suitable electrical loads. Its 230 V AC, 50/60 Hz supply supports standard mains-powered installations, while its 21 selectable operating functions allow the relay to be configured for impulse switching, monostable operation, timed control and selected automation applications.
The Finder 13.72.8.230.B002 anthracite grey multifunction relay supports wireless operation through the YESLY Bluetooth ecosystem and smartphone control using the Finder YOU application. Configuration is available through Finder TOOLBOX Plus, while two wired push-button inputs provide conventional local control. Its compatibility with selected AVE, BTicino, Gewiss, Simon Urmet and Vimar modular switch ranges makes it a practical solution for modern residential and commercial electrical installations.
Key Advantages
- 2 independently programmable channels provide flexible control of separate electrical circuits.
- 2 normally open contacts rated at 6 A support compatible lighting and auxiliary loads.
- 21 selectable operating functions allow the relay to be adapted to different switching requirements.
- Bluetooth Low Energy connectivity enables wireless operation within compatible YESLY installations.
- Anthracite grey finish suits matching contemporary modular switch accessories.
- Finder YOU app compatibility supports convenient smartphone operation.
- Two wired push-button inputs maintain conventional local switching control.
- Supports up to 8 programmable scenarios within the YESLY system.
- Impulse, monostable and other programmable relay functions provide installation flexibility.
- Compatible with selected Italian-style modular switch systems.
- Compact design supports installation within suitable wall-switch assemblies.
- Suitable for lighting automation, auxiliary switching and selected shutter-control applications.
Key Features
- Finder 13 Series YESLY multifunction electronic relay.
- Model 13.72.8.230.B002.
- Anthracite grey colour variant.
- 2 independent programmable switching channels.
- 2 normally open (NO) output contacts.
- 6 A contact rating at 230 V AC.
- 230 V AC nominal supply voltage.
- 50/60 Hz supply frequency.
- 21 selectable operating functions.
- Default impulse relay function on both channels.
- Monostable, bistable and timed switching capabilities.
- Programmable roller shutter control function for compatible applications.
- 2 wired push-button inputs, one per channel.
- Supports up to 5 illuminated push-buttons per input.
- Bluetooth 4.2 Low Energy communication.
- 128-bit encrypted wireless communication.
- Approximate Bluetooth range of 10 m in unobstructed free space.
- Supports up to 8 YESLY scenarios.
- Smartphone control using Finder YOU.
- Installer configuration using Finder TOOLBOX Plus.
- Compatible with selected modular wall-switch ranges using appropriate adapters.
- IP20 protection rating.
Flexible Bluetooth Switching and Intelligent Lighting Control
The Finder 13.72.8.230.B002 provides two independent relay channels that can be configured for different control functions. Each channel has a normally open output rated at 6 A, allowing compatible electrical loads to be switched through conventional push-buttons or wireless YESLY controls. With 21 selectable functions, the device can operate as an impulse relay, perform timed switching or support application-specific control arrangements. Its TP function also permits complete opening and closing control of compatible roller shutters, while other configurations can support applications such as bathroom fan and lighting combinations.
Bluetooth communication enables the relay to become part of a wider Finder YESLY smart home installation. The Finder YOU application provides smartphone operation and scenario management, while Finder TOOLBOX Plus allows installers to configure operating functions. The anthracite grey version is designed for integration with selected modular wall-switch ranges, using the appropriate mounting adapter. Its compact construction makes it suitable for upgrading conventional electrical switching installations with wireless automation capabilities.
Typical Applications
- Residential smart lighting control.
- Finder YESLY Bluetooth home automation installations.
- Independent switching of two lighting circuits.
- Bedroom and living room lighting automation.
- Commercial office lighting control.
- Corridor and common-area lighting systems.
- Bathroom extractor fan and lighting control.
- Doorbell and auxiliary lighting combinations.
- Compatible motorised roller shutter control.
- Timed electrical switching applications.
- Wireless push-button control systems.
- Smartphone-operated electrical installations.
- Modernisation of compatible modular wall-switch assemblies.
- Residential refurbishment and smart home upgrades.
- Small commercial building automation systems.
