Yaskawa PG-X3 line driver encoder feedback option card for compatible Yaskawa AC drives, enabling incremental encoder feedback for V/f with PG, Closed Loop Vector, Advanced Open Loop Vector and PM motor control applications.
£68.00
The Yaskawa PG-X3 is a line driver encoder feedback option card designed for compatible Yaskawa AC drives. It enables the drive to receive high-speed incremental encoder feedback from the motor, improving speed regulation, torque performance and overall control accuracy in closed-loop applications.
The PG-X3 supports V/f with PG, Closed Loop Vector (CLV), Advanced Open Loop Vector (AOLV) and Closed Loop Vector for PM motors (CLV/PM) control methods. Encoder feedback allows the drive to compensate for load variations and maintain accurate motor speed under changing operating conditions.
By monitoring encoder signals directly from the motor, the PG-X3 allows the drive to detect speed variations caused by changing loads. The drive can then adjust output frequency and torque more accurately, helping maintain stable speed, improved responsiveness and higher control performance.
The PG-X3 is intended for line driver encoders. For applications using open collector encoder outputs, Yaskawa specifies the use of the PG-B3 option instead.
| Product type | Encoder feedback option card |
|---|---|
| Encoder type | Incremental encoder (line driver) |
| Signal type | Differential line driver encoder signals |
| Supported encoder channels | A, B and Z phase |
| Maximum encoder input frequency | 300 kHz |
| Encoder supply voltage | 5 V DC or 12 V DC selectable |
| Control modes | V/f with PG, CLV, AOLV and CLV/PM |
| Function | Motor speed feedback and closed-loop control enhancement |
| Installation | Internal drive option card |
| Compatible drive series | A1000, L1000A, U1000, U1000L, GA700, GA800, CR700, CH700 and LA700 |
| EMC Filter | None |
The PG-X3 connects an incremental line driver encoder to a compatible Yaskawa drive to provide motor speed feedback and improve control accuracy.
The PG-X3 is designed for incremental encoders with differential line driver output signals.
The PG-X3 can process encoder feedback signals up to 300 kHz.
The option supports V/f with PG, Closed Loop Vector (CLV), Advanced Open Loop Vector (AOLV) and Closed Loop Vector for PM motors (CLV/PM).
No. The PG-X3 is intended for line driver encoders. Yaskawa recommends the PG-B3 option for open collector encoder applications.
