Why Choose the ABB OTDC25U4 PV Disconnect Switch?
The ABB OTDC25U4 (1SCA134377R1001) is a compact and dependable DC PV disconnect switch engineered to provide safe isolation for photovoltaic (PV), battery energy storage and industrial direct current applications. As part of the trusted ABB OTDC switch disconnector series, it delivers reliable switching performance while complying with IEC 60947-3 and UL 508i standards for renewable energy installations.
Designed for OEMs, panel builders and electrical contractors, the OTDC25U4 features a 4-pole double-circuit configuration with base or DIN rail mounting, making it ideal for isolating multiple photovoltaic strings. Its compact footprint, touch-safe IP20 terminals and flexible installation simplify panel assembly while ensuring dependable long-term performance.
With a 25 A operational rating at 600 V DC (UL), 25 A at 660 V DC (IEC) and 16 A at 1000 V DC (IEC), the ABB OTDC25U4 provides dependable DC isolation for solar installations and industrial DC applications. A terminal bolt kit is included, while compatible operating handles and shafts are supplied separately.
Key Advantages
- Compact DC PV disconnect switch for safe circuit isolation.
- 25 A switching capacity for higher current photovoltaic installations.
- 4-pole double-circuit configuration for multiple PV strings.
- Suitable for base or DIN rail mounting.
- Touch-safe IP20 protected terminal clamps.
- Reliable ABB switching technology for demanding industrial environments.
Key Features
- ABB OTDC switch disconnector series.
- Model: OTDC25U4.
- Manufacturer part number: 1SCA134377R1001.
- 25 A at 600 V DC (UL).
- 25 A at 660 V DC (IEC).
- 16 A at 1000 V DC (IEC).
- 4-pole double-circuit configuration.
- Base or DIN rail mounting.
- Terminal bolt kit included.
- Handles and shafts available separately.
Reliable DC Isolation for Solar Energy Systems
DC disconnect switches provide a safe means of isolating photovoltaic strings during installation, maintenance and servicing. The ABB OTDC range has been specifically developed for renewable energy applications, delivering dependable switching performance and long service life in demanding operating environments.
The OTDC25U4 combines ABB's proven engineering with compact construction, enabling straightforward integration into photovoltaic arrays, battery storage systems and industrial DC installations while maintaining high levels of safety and reliability.
Typical Applications
- Solar photovoltaic systems.
- PV combiner boxes.
- Battery energy storage systems.
- Industrial DC distribution panels.
- Renewable energy installations.
- OEM electrical control equipment.
