ABB OTHV630E04P four-pole 630A switch disconnector with black pistol handle and operating shaft for 800–1000 V AC industrial electrical isolation.
£1,052.12
The ABB OTHV630E04P, product code 1SCA162991R1001, is a premium four-pole switch disconnector engineered to provide safe electrical isolation and dependable switching for industrial installations operating between 800 and 1000 V AC. As part of the ABB OTHV high-voltage switch disconnector range, it is designed for demanding applications including industrial power distribution, renewable energy systems, OEM machinery and process automation.
This front-operated, base-mounted switch disconnector is supplied as a complete package with a black IP65 pistol handle and adjustable operating shaft, allowing rapid installation into switchboards and electrical control panels. The supplied handle is padlockable in the OFF position and incorporates door interlocking for enhanced operator safety, while phase barriers are supplied as standard.
With a 630 A rated operational current for AC-21A and AC-22A applications, a 400 A AC-23A rating, 12 kV impulse withstand voltage and robust ABB construction, the OTHV630E04P delivers dependable long-term performance in demanding high-voltage industrial environments.
The ABB OTHV630E04P is designed to safely isolate high-voltage electrical circuits before maintenance, inspection or servicing. Its four-pole construction enables simultaneous disconnection of all conductors, making it ideal for industrial switchboards, renewable energy installations and high-voltage distribution systems where dependable isolation is essential.
The supplied IP65 pistol handle provides convenient external operation while allowing door interlocking and padlocking in the OFF position. Combined with ABB's proven switching mechanism, the OTHV630E04P offers a dependable and flexible solution for OEM equipment, industrial automation and electrical infrastructure.
| Current | 630 A |
|---|---|
| Voltage | 800 V |
| Phase | Three Phase |
| IP Rating | IP00 |
| Manufacturer | ABB |
| Series | OTHV |
| Model | OTHV630E04P |
| Manufacturer Part Number | 1SCA162991R1001 |
| Alternative SKU | OTHV630E04P |
| Product Type | Switch Disconnector |
| Number of Poles | 4 |
| Operation | Front operated |
| Mounting | Base mounted |
| Rated Operational Voltage | 800–1000 V AC |
| Rated Insulation Voltage (Ui) | 1000 V |
| Rated Operational Current (AC-21A / AC-22A) | 630 A |
| Rated Operational Current (AC-23A) | 400 A |
| Conventional Thermal Current (Ith) | 630 A |
| Rated Impulse Withstand Voltage (Uimp) | 12 kV |
| Terminal Type | Lug terminals, 39 mm |
| Mechanical Durability | 10,000 operations |
| Protection Rating | IP00 (switch), IP65 (handle) |
| Dimensions (H × W × D) | 250 × 331 × 140 mm |
| EAN | 6417019929439 |
| Country of Origin | Finland |
| Included Accessories | Black pistol handle, adjustable operating shaft and phase barriers |
| HS Code | 85365080 |
| Country of Manufacture | Finland |
It provides safe manual switching and electrical isolation for industrial electrical systems operating between 800 and 1000 V AC.
Yes. The OTHV630E04P is supplied complete with a black IP65 pistol handle, adjustable operating shaft and phase barriers.
This model features a four-pole switching configuration for simultaneous isolation of all conductors.
The switch is rated at 630 A for AC-21A and AC-22A applications, with a 400 A AC-23A rating.
It is commonly installed in industrial switchboards, renewable energy installations, OEM machinery and electrical distribution systems requiring reliable high-voltage isolation.
ABB OTHV switch disconnectors are trusted by panel builders, OEM manufacturers and electrical engineers for dependable electrical isolation, robust switching performance and long-term industrial reliability.
