Wöhner 01190 tin-plated double-T section Cu-ETP copper busbar with a 720 mm² cross-section, 3.60 m length and verified 1600 A IEC current capacity for industrial power distribution.
£597.49
The Wöhner 01190 is a heavy-duty tinned double-T section copper busbar designed for high-current industrial power distribution systems. As part of the proven Wöhner 60Classic centre-feed system, it provides a dependable solution for switchboards, distribution assemblies and OEM electrical equipment requiring reliable, high-capacity current distribution.
Manufactured from high-conductivity Cu-ETP copper (CW004A) in accordance with EN 13601, the busbar features a 720 mm² cross-sectional area and is supplied in a 3.60 metre length. Its durable tin-plated finish reduces contact preparation time while providing effective protection against corrosion and aggressive industrial environments.
With a verified IEC current capacity of 1,600 A and a UL current rating of 1,400 A for feeder circuits above 250 V, the Wöhner 01190 delivers excellent electrical and mechanical performance for demanding industrial applications.
Double-T section busbars provide an efficient method of distributing high electrical currents throughout industrial switchboards while maintaining excellent mechanical rigidity. Their specialised profile supports compatible connection technology and helps ensure secure, low-resistance electrical connections throughout the installation.
The Wöhner 01190 combines high-purity Cu-ETP copper with a durable tin-plated surface to reduce installation time while improving long-term corrosion resistance. It is ideal for demanding industrial applications requiring dependable power distribution and compatibility with the Wöhner 60Classic centre-feed system.
| Manufacturer | Wöhner |
|---|---|
| Series | 60Classic Centre Feed |
| Model | 01190 |
| Full article number | 01190 000 |
| Product type | Double-T section busbar |
| Material | Cu-ETP copper (CW004A) |
| Copper purity | 99.9% |
| Material standard | EN 13601 |
| Strength class | R300 (300 N/mm²) |
| Finish | Tin-plated |
| Cross-sectional area | 720 mm² |
| Length | 3.60 m |
| IEC verified current | 1,600 A |
| UL maximum load | 1,400 A |
| Power dissipation at 80% load | 174.7 W |
| Power dissipation at full load | 273.0 W |
| Minimum operating temperature | -40°C |
| Dimensions (W × H × D) | 3600 × 30 × 40 mm |
| Approximate weight | 23.34 kg |
| Type number | H720-L |
| Pack quantity | 1 |
| EAN | 4021267011901 |
| Approvals | CSA, UL, DNV GL |
| Standards | IEC 61439-1:2020, UL 508 |
| HS Code | 74071000 |
| Country of Manufacture | Belgium |
The Wöhner 01190 is a double-T section copper busbar used for distributing high electrical currents within industrial switchboards and Wöhner 60Classic centre-feed systems.
It is manufactured from high-conductivity Cu-ETP copper (CW004A) with 99.9% copper content and a durable tin-plated finish.
The busbar is supplied in a 3.60 metre length.
The busbar has a verified IEC current capacity of 1,600 A and a UL maximum load of 1,400 A under the manufacturer's specified conditions.
The tin-plated finish reduces contact preparation work while providing effective protection against corrosion and aggressive industrial environments.
Wöhner busbar systems are trusted by switchgear manufacturers, panel builders and electrical engineers for dependable high-current power distribution, robust construction and long-term industrial reliability.
