Wöhner 01628 tin-plated Cu-ETP copper busbar measuring 60 × 10 mm with a 600 mm² cross-sectional area, 2.4 metre length and tested 1,250 A current value for heavy-duty industrial power distribution.
£386.71
The Wöhner 01628 is a heavy-duty tin-plated copper busbar engineered for high-current power distribution in industrial switchgear, distribution panels and low-voltage electrical assemblies. Manufactured from 99.9% Cu-ETP copper (CW004A) in accordance with EN 13601, it provides excellent electrical conductivity, robust mechanical strength and dependable long-term performance.
Its factory-applied tin-plated finish substantially reduces the preparation required at electrical contact points. The coating also protects the copper against oxidation and aggressive industrial environments, helping panel builders and electrical engineers create reliable connections while reducing assembly and maintenance requirements.
With dimensions of 60 × 10 mm, a 2.4 metre length and a substantial 600 mm² cross-sectional area, the Wöhner 01628 is suitable for demanding high-current installations. It supports a tested current of 1,250 A at a 30 K temperature rise under specified IEC test conditions and a maximum load of 1,100 A according to UL 508.
Copper busbars provide a low-resistance electrical path for carrying substantial currents through switchgear and industrial distribution equipment. Their large conductive area helps reduce voltage drop and power losses while supporting compact, organised and mechanically robust electrical assemblies.
The Wöhner 01628 combines a high-capacity copper cross-section with a corrosion-resistant tin-plated surface. This makes it a practical choice for professional installations where high current capability, reliable electrical contact and long service life are essential.
| Manufacturer | Wöhner |
|---|---|
| Series | 185Power / 100Energy |
| Model | 01628 |
| Full part number | 01628 000 |
| Product type | Tin-plated copper busbar |
| Material | Cu-ETP copper (CW004A), 99.9% copper |
| Finish | Tin-plated |
| Dimensions | 60 × 10 mm |
| Cross-sectional area | 600 mm² |
| Length | 2.4 m |
| Tested current at 30 K | 1,250 A |
| Maximum load according to UL 508 | 1,100 A |
| Strength class | R300, 300 N/mm² |
| Minimum operating temperature | -40°C |
| Power dissipation at 80% load | 78.7 W |
| Power dissipation at full load | 123 W |
| Edge radius | 0.5 mm |
| Standards | IEC 61439-1:2020, UL 508 |
| Approval | UL |
| UL type number | 60x10-L |
| Halogen-free | Yes |
| Weight | Approx. 12.94 kg |
| EAN | 4021267016289 |
| Pack quantity | 1 |
| HS Code | 74071000 |
| Country of Manufacture | Belgium |
The Wöhner 01628 is used for high-current electrical power distribution in industrial switchgear, main distribution panels and compatible Wöhner busbar systems.
The busbar measures 60 × 10 mm, has a 600 mm² cross-sectional area and is supplied in a 2.4 metre length.
The busbar has a tested current value of 1,250 A at a 30 K temperature rise under specified IEC conditions and a maximum load of 1,100 A according to UL 508.
The tin-plated finish reduces contact-point preparation, improves resistance to oxidation and protects the copper against aggressive environmental conditions.
The Wöhner 01628 is designed for use with the 185Power and 100Energy busbar systems.
Wöhner busbar components are widely specified by panel builders, switchgear manufacturers and industrial engineers for dependable high-current distribution, robust construction and efficient installation.
