Why Choose the ABB ZE60 Busbar Mounting Fuse Base E18?
The ABB ZE60 is a compact Neozed busbar-mounting fuse base designed for protected power distribution within ABB sub-distribution assemblies. As part of the ABB DESUJ Sub Distribution range, it provides a practical method of mounting E18 threaded fuse protection directly within compatible busbar systems.
This fuse base is designed for three-pole applications and accommodates gauge ring inserts for correctly matched fuse protection. It is supplied with covers and nameplates to support organised, clearly identified installation within electrical distribution equipment.
With an E18 fuse thread, a compact 26 mm width and compatibility with safety fuses rated up to 63 A, the ZE60 is suited to sub-distribution systems where space-efficient and dependable circuit protection is required.
Key Advantages
- Compact busbar-mounting fuse base for sub-distribution systems.
- Designed for Neozed E18 threaded fuses.
- Supports safety fuses up to 63 A.
- Three-pole configuration for three-phase distribution applications.
- Compatible with gauge ring inserts for correctly matched fuse ratings.
- Supplied with covers and nameplates for organised installation and identification.
Key Features
- ABB DESUJ Sub Distribution range.
- Neozed busbar-mounting fuse socket.
- E18 threaded fuse interface.
- Maximum fuse rating: 63 A.
- 3-pole construction.
- 26 mm overall width.
- Designed for use with gauge ring inserts.
- Includes covers and nameplates.
Reliable Fuse Protection for Sub-Distribution Systems
Busbar-mounted fuse bases such as the ABB ZE60 provide a compact connection point for protective fuses within electrical distribution assemblies. Correctly rated fuses interrupt excessive current caused by overloads or short circuits, helping protect downstream wiring and connected equipment.
The ZE60 is designed for integration into ABB sub-distribution equipment where compact three-pole fuse protection is required. Its E18 Neozed format, gauge ring compatibility and busbar-mounted construction support efficient installation and straightforward maintenance within distribution panels.
Typical Applications
- Electrical sub-distribution boards.
- Industrial distribution panels.
- Three-phase fused circuits.
- Busbar-based power distribution assemblies.
- Commercial building electrical distribution.
- Control and switchgear cabinets requiring compact fuse protection.
