Why Choose the Rittal RX9360.008 RiLineX Board?
The Rittal RX9360.008 RiLineX Board is a fully assembled three-pole power distribution board designed for high-current industrial switchgear and control panel applications. Supplied complete with integrated 30 × 10 mm E-Cu copper busbars, it is rated at up to 800A and provides a ready-to-install solution that significantly reduces panel assembly time while ensuring dependable electrical performance.
Designed for installation in 1000 mm-wide enclosures, the board measures 905 mm in length and features comprehensive IP2XB touch protection, upgradeable to IP3X with compatible accessories. It is suitable for horizontal, vertical or overhead mounting and incorporates an integrated rear cable-routing area to simplify enclosure wiring.
The RX9360.008 supports electrical systems operating at up to 1000V AC or 1500V DC and has been tested for 65kA short-circuit withstand capability. Certified to both IEC 61439 and UL 508, it provides a robust platform for industrial power distribution systems requiring high reliability and straightforward future expansion.
Key Advantages
- Complete pre-assembled RiLineX board with integrated copper busbars.
- High 800A current rating.
- Designed for 1000 mm-wide enclosures.
- Suitable for 1000V AC and 1500V DC systems.
- IP2XB touch protection, upgradeable to IP3X.
- Tested short-circuit withstand up to 65kA.
- Suitable for horizontal, vertical and overhead installation.
- Simple baying with compatible RiLineX connector sets.
- Integrated rear cable routing.
- IEC and UL certified.
Key Features
- Rittal RiLineX complete board.
- Article number RX9360.008.
- Three-pole construction.
- Integrated E-Cu copper busbars.
- 30 × 10 mm busbar dimensions.
- 60 mm busbar centre spacing.
- 800A IEC and UL rated current.
- IP2XB protection.
- 12kV impulse withstand voltage.
- 143kA impulse withstand current.
- 65kA short-time withstand current (500 ms).
- Polyamide PA6 insulating structure.
- Fire behaviour in accordance with UL 94.
Efficient High-Current Power Distribution
The RX9360.008 serves as the primary power distribution platform within RiLineX switchboards. Its integrated copper busbars provide a robust connection point for compatible RiLineX adaptors, switch disconnectors and protective devices, enabling efficient distribution of high electrical loads throughout industrial installations.
Because the board is supplied fully assembled, installation is considerably faster than conventional busbar fabrication. It also allows straightforward extension using compatible RiLineX baying connectors, enabling larger switchboard systems to span multiple enclosures without compromising electrical performance.
Typical Applications
- Industrial low-voltage switchgear.
- Main power distribution boards.
- Motor control centres.
- OEM electrical panels.
- Industrial automation systems.
- Commercial electrical infrastructure.
- Renewable energy installations.
- Battery energy storage systems.
- Data centre power distribution.
- Large modular enclosure line-ups.
