Why Choose the ABB WR18 Mounting Frame 1PW?
The ABB WR18 is a robust WR mounting frame designed for structured installation of electrical equipment and modules within compatible ABB floor-standing and row-mounted distribution cabinets. Supplied under ABB order code 2CPX034801R9999, the WR18 provides a 1-panel-width (1PW) mounting structure for professional sub-distribution and switchgear assemblies.
The WR18 has an overall height 8 (OH8) configuration corresponding to 12 RE, with a frame length of 1800 mm and a field width of 250 mm. Its construction incorporates vertical WR profile rails with transverse profile rails, creating a versatile support structure for free assembly and compatible ABB installation systems.
Manufactured from galvanised steel, the WR18 is designed for durable installation within compatible standing and row switching cabinets. The frame is suitable for cabinets with sufficient installation depth and can be used for free assembly, installation of compatible EDF WNF installation sets and mounting of modular equipment as part of coordinated ABB distribution systems.
Key Advantages
- Genuine ABB WR mounting frame for professional electrical distribution assemblies.
- 1-panel-width (1PW) format provides a compact, structured equipment mounting area.
- Overall height 8 (OH8) configuration with 12 RE.
- 1800 mm frame length for full-height floor-standing cabinet installations.
- Robust galvanised steel construction for dependable mechanical support.
- Suitable for free assembly and installation of compatible modular equipment.
- Supports integration with compatible ABB CombiLine and EDF installation components.
Key Features
- ABB WR18 mounting frame.
- ABB order code 2CPX034801R9999.
- 1PW / OH8 configuration.
- 12 RE height units.
- 1800 mm length.
- 250 mm field width.
- Vertical WR profile rails with transverse profile rails.
- Steel construction.
- Screw-fixed mounting arrangement.
- 40 mm mounting rail profile height.
- Suitable for compatible ABB floor-standing and row switching cabinets.
- Designed for coordinated ABB sub-distribution and switchgear systems.
Flexible Mounting for Electrical Distribution Systems
Mounting frames such as the ABB WR18 provide the structural foundation needed to arrange electrical equipment securely within professional distribution and switchgear cabinets. The WR profile system provides defined mounting points for compatible components while allowing panel builders to create equipment layouts suited to the requirements of each installation.
The WR18 is particularly suited to free assembly and modular ABB distribution systems. Its 1PW format, 12 RE overall height and galvanised steel construction provide a durable framework for compatible CombiLine modules, EDF installation components and other equipment within appropriately sized ABB floor-standing cabinets.
Typical Applications
- ABB floor-standing electrical distribution cabinets.
- Row-mounted switchgear cabinets.
- ABB CombiLine modular distribution systems.
- Electrical sub-distribution assemblies.
- Free assembly of compatible electrical equipment.
- EDF WNF installation set mounting.
- Commercial and industrial switchboard construction.
- Professional electrical panel-building projects.
