Why Choose the ABB WR38 Mounting Frame?
The ABB WR38 is a robust WR mounting frame for ABB floor-standing and row switchgear cabinets, providing a structured internal framework for professional low-voltage distribution assemblies. With a 3 PW field width, overall height 8 and 12 grid units, it provides substantial mounting capacity for compatible electrical equipment and modular installation systems.
The WR38 consists of vertical WR profile rails with cross-profile rails, creating a stable framework for free-form equipment installation and compatible modular assemblies. Its steel construction and screw-fixed mounting arrangement provide dependable mechanical support within suitable ABB cabinet systems.
With a frame length of 1800 mm, the WR38 is designed for compatible floor-standing and row switchgear cabinets from 225 mm cabinet depth. It is also used when installing compatible EDF WNF installation sets from a cabinet depth of 425 mm and when assembling modules on the WR mounting frame.
Key Advantages
- Dedicated 3 PW WR mounting frame for ABB cabinet systems.
- Provides 432 space units across its 3-panel-wide configuration.
- 12 grid units with overall height 8 for structured equipment installation.
- Robust steel construction for professional cabinet assemblies.
- Vertical WR profile rails and cross-profile rails support flexible equipment layouts.
- Suitable for compatible floor-standing and row switchgear cabinets from 225 mm depth.
Key Features
- ABB CombiLine WR mounting system.
- Model WR38.
- 3 PW field width.
- 432 space units.
- Overall height 8.
- 12 grid units.
- 1800 mm frame length.
- 40 mm support rail profile height.
- Vertical WR profile rails with cross-profile rails.
- Steel construction.
- Screw-fixed mounting arrangement.
- Suitable for free-form assembly and compatible modular installation systems.
- ABB order code 2CPX034803R9999.
Flexible Internal Mounting for Distribution Cabinets
WR mounting frames provide the structural foundation required to arrange electrical equipment securely within compatible floor-standing and row switchgear cabinets. The profile-based construction gives panel builders flexibility when positioning equipment, installation sets and modular assemblies while maintaining an organised internal cabinet structure.
The ABB WR38 provides a 3 PW, 12-grid-unit mounting structure for compatible ABB cabinet systems. It supports free-form assembly directly on the WR mounting frame and can be combined with appropriate ABB EDF WNF installation sets and modular equipment, making it a versatile foundation for professional low-voltage distribution construction.
Typical Applications
- ABB floor-standing distribution cabinets.
- ABB row switchgear cabinet systems.
- Low-voltage sub-distribution assemblies.
- Free-form electrical equipment mounting.
- Compatible EDF WNF installation-set assemblies.
- CombiLine modular distribution equipment installations.
