Why Choose the ABB WR48 WR Mounting Frame?
The ABB WR48 is a robust WR mounting frame designed for the structured installation of electrical equipment and modules within compatible ABB floor-standing and modular cabinets. With a 4 panel-width (4PW) configuration and overall height 8, it provides a purpose-designed internal framework for professional electrical distribution assemblies.
The WR48 consists of vertical WR profile rails with cross-profile rails and provides 12 grid units across a total length of 1800 mm. It is suitable for compatible floor-standing and modular cabinets with a depth of at least 225 mm, providing a coordinated mounting structure for flexible cabinet assembly.
Manufactured from steel, the ABB WR48 is designed for screw-fixed installation and can be used for free assembly, for mounting suitable modules and with the EDF WNF installation set where applicable. ABB identifies the product under order code 2CPX034804R9999, ensuring precise identification for specification, replacement and procurement.
Key Advantages
- Purpose-designed WR mounting frame for ABB electrical cabinets.
- 4 panel-width (4PW) configuration for larger cabinet assemblies.
- 1800 mm overall length with 12 grid units.
- Suitable for compatible cabinets from 225 mm depth.
- Vertical and cross-profile rail construction supports flexible internal equipment mounting.
- Robust steel construction for professional distribution and panel-building applications.
Key Features
- ABB WR mounting frame.
- 4 panel widths (4PW).
- Overall height 8.
- 12 grid units.
- 1800 mm length.
- 40 mm support-rail profile height.
- Constructed from steel.
- Vertical WR profile rails with cross-profile rails.
- Screw-fixed mounting.
- Suitable for compatible floor-standing and modular cabinets from 225 mm depth.
- ABB order code 2CPX034804R9999.
Reliable Equipment Mounting for Electrical Distribution Cabinets
Mounting frames provide the internal structural framework required to organise electrical equipment, installation sets and modules inside distribution cabinets. A coordinated mounting system helps panel builders position components securely while maintaining an orderly and adaptable cabinet layout.
The ABB WR48 provides a 4PW, 12-grid-unit mounting structure for compatible floor-standing and modular cabinets. It can support free assembly on the WR framework, suitable module installations and the EDF WNF installation set in compatible cabinets from 425 mm depth.
Typical Applications
- ABB floor-standing electrical cabinets.
- Compatible modular and row-mounted cabinets.
- CombiLine electrical distribution assemblies.
- Free assembly of electrical equipment on WR mounting structures.
- Mounting compatible electrical distribution modules.
- Panel-building and switchgear installations.
