Why Choose the ABB 1V3A Distribution Panel?
The ABB 1V3A is a 1 PW distribution panel designed for DIN rail-mounted modular devices within compatible ABB low-voltage distribution cabinets. Part of the ABB internal expansion system, it is mounted on EDF profile rails and provides a structured installation platform for professional electrical sub-distribution assemblies.
Configured with 7 GU and a field width of 1 PW / 250 mm, the 1V3A provides 84 space units across seven DIN rail rows. Each rail accommodates 12 modular spaces, with 125 mm row spacing and 35 × 15 mm perforated DIN rails for modular devices manufactured to DIN 43880.
The panel measures 250 mm wide × 1050 mm high and is suitable for compatible cabinets from 120 mm depth. Plastic covers with equipment cut-outs, 90-degree press-and-turn closures and a RAL 7035 finish provide a coordinated protective front arrangement, while the required EDF profile rails are included in the scope of delivery.
Key Advantages
- Purpose-designed 1 PW distribution panel for DIN rail-mounted devices.
- 7 GU / 1050 mm configuration for high-capacity modular installations.
- Provides 84 space units across seven DIN rail rows.
- 12 modular spaces per DIN rail for organised equipment installation.
- 125 mm row spacing supports a structured cabinet layout.
- EDF profile rails included for integration into compatible ABB cabinets.
Key Features
- ABB internal expansion distribution panel system.
- Model designation 1V3A.
- 1 PW / 250 mm field width.
- 7 GU / 1050 mm panel height.
- 84 space units.
- Seven DIN rail rows.
- 12 modular spaces per DIN rail.
- 125 mm row spacing.
- 35 × 15 mm perforated DIN rails.
- Plastic covers with equipment cut-outs.
- 90° press-and-turn closures.
- EDF profile rails included.
High-Capacity DIN Rail Distribution for Professional Cabinets
DIN rail distribution panels provide an organised mounting platform for modular protection, switching and control devices within low-voltage cabinets. Standardised rail dimensions and spacing help panel builders create consistent assemblies while maintaining convenient access to installed equipment for wiring, inspection and servicing.
The ABB 1V3A provides seven horizontal DIN rail rows with 12 modular spaces per row, delivering a total capacity of 84 space units. Its 125 mm row spacing, protective covers and included EDF profile rails make it a coordinated solution for integrating DIN 43880 modular equipment into compatible ABB distribution cabinets.
Typical Applications
- Low-voltage electrical distribution cabinets.
- DIN rail modular device installations.
- ABB modular sub-distribution systems.
- Commercial building electrical distribution.
- Industrial power and control assemblies.
- Protection, switching and control device installations.
- Panel building and electrical system integration.
