Why Choose the ABB ED91KA Terminal Plate?
The ABB ED91KA (2CPX037824R9999) is a professional 1-panel-width terminal plate combination set designed for horizontal terminal-block mounting within compatible ABB sub-distribution cabinets. Part of the ABB DESUJ Sub Distribution product group, it provides a structured termination area for organising terminal blocks and associated wiring within professional electrical distribution assemblies.
The ED91KA is mounted on EDF profiles and uses horizontal 35 × 7.5 mm DIN rails with perforations for wire holders. Its 150 mm row spacing provides practical working room for terminal blocks and conductor routing, while the combination-set design enables integration with compatible ABB distribution panels.
With a height of 450 mm, width of 250 mm and a 1 PW format, the ED91KA occupies three grid units and provides 36 space units. Plastic covers finished in RAL 7035 with 90-degree press-and-turn closures are included, while EDF profile rails and field connectors support installation in compatible ABB cabinets from 200 mm depth.
Key Advantages
- Purpose-designed 1 PW terminal plate combination set for ABB sub-distribution systems.
- Horizontal DIN rail arrangement specifically suited to terminal blocks.
- 35 × 7.5 mm DIN rails with perforations for wire holders.
- 150 mm row spacing provides practical room for termination and conductor routing.
- Compact 250 mm-wide single-field configuration.
- Plastic covers provide a neat and protected internal installation.
- 90-degree press-and-turn closures provide convenient access.
- EDF profile rails and field connectors are included for straightforward system integration.
Key Features
- ABB ED91KA terminal plate.
- 1 PW / 250 mm field width.
- 3 grid units / 450 mm height.
- 36 space units.
- Designed for horizontally arranged terminal blocks.
- 35 × 7.5 mm horizontal DIN rails.
- DIN rails feature perforations for wire holders.
- 150 mm row spacing.
- Plastic covers finished in RAL 7035.
- 90-degree press-and-turn cover closures.
- Suitable for cabinets from 200 mm depth.
- EDF profile rails and field connectors included.
Organised Terminal Block Mounting for ABB Distribution Systems
Terminal mounting assemblies provide a dedicated area for organising conductor terminations within electrical distribution cabinets. The ABB ED91KA uses horizontal 35 × 7.5 mm DIN rails with 150 mm row spacing, providing an accessible mounting arrangement for compatible terminal blocks while allowing conductors to be routed and organised efficiently.
The ED91KA forms part of ABB's internal expansion combination-set system and is designed to work with compatible distribution panels rather than as a standalone enclosure. Its EDF profile mounting, included field connectors and protective covers provide a practical foundation for creating structured terminal areas within professional sub-distribution assemblies.
Typical Applications
- Electrical sub-distribution boards.
- Terminal block mounting and termination areas.
- Commercial building electrical distribution.
- Industrial electrical and control cabinets.
- Conductor termination and organisation.
- Control and automation panel wiring.
- Panel-building and switchboard applications.
- ABB internal expansion and EDF profile systems.
