Why Choose the ABB ED92KA Terminal Plate?
The ABB ED92KA (2CPX037825R9999) is a professional 2-panel-width terminal plate combination set designed for horizontal terminal-block mounting within compatible ABB sub-distribution cabinets. Part of the ABB DESUJ Sub Distribution product group, it provides a structured termination area for organising terminal blocks and associated wiring within professional electrical distribution assemblies.
The ED92KA is mounted on EDF profiles and uses horizontal 35 × 15 mm DIN rails for terminal blocks. The rails can be configured for protective insulation using the ABB ZK90P2 insulator piece where required, while the 150 mm row spacing can be repositioned when necessary to suit the installation and conductor-routing requirements.
With a height of 450 mm, width of 500 mm and a 2 PW format, the ED92KA occupies three grid units and provides 72 space units. Designed for cabinets from 200 mm depth, the combination set is installed with a compatible distribution panel, providing a practical terminal mounting solution for larger ABB sub-distribution assemblies.
Key Advantages
- Purpose-designed 2 PW terminal plate combination set for ABB sub-distribution systems.
- Horizontal DIN rail arrangement designed for terminal-block installation.
- 35 × 15 mm DIN rails provide a standardised terminal mounting platform.
- 150 mm adjustable row spacing supports flexible terminal and conductor layouts.
- Can be configured for protective insulation using the optional ABB ZK90P2 insulator piece.
- 500 mm-wide two-panel configuration provides substantial termination capacity.
- 72 space units within a compact three-grid-unit format.
- Designed for straightforward integration with compatible ABB distribution panels and cabinets.
Key Features
- ABB ED92KA terminal plate.
- 2 PW / 500 mm field width.
- 3 grid units / 450 mm height.
- 72 space units.
- Designed for horizontally arranged terminal blocks.
- 35 × 15 mm horizontal DIN rails.
- 150 mm adjustable row spacing.
- Protective insulation possible using optional ZK90P2 insulator pieces.
- Suitable for cabinets from 200 mm depth.
- Designed for ABB EDF profile-based internal expansion systems.
High-Capacity Terminal Block Mounting for ABB Distribution Systems
Terminal mounting assemblies provide a dedicated area for organising conductor terminations within electrical distribution cabinets. The ABB ED92KA combines a wide 2 PW format with horizontal 35 × 15 mm DIN rails and 150 mm row spacing, providing an accessible mounting arrangement for compatible terminal blocks while allowing conductors to be routed and organised efficiently.
The ED92KA forms part of ABB's internal expansion combination-set system and is intended to work with compatible distribution panels rather than as a standalone enclosure. Its 72-space-unit capacity and adjustable rail arrangement make it particularly suitable for larger termination areas where flexibility, accessibility and structured wiring are important.
Typical Applications
- Electrical sub-distribution boards.
- High-capacity terminal block mounting areas.
- Commercial building electrical distribution.
- Industrial electrical and control cabinets.
- Conductor termination and organisation.
- Control and automation panel wiring.
- Panel-building and switchboard applications.
- ABB internal expansion and EDF profile systems.
