Why Choose the ABB MG101 Modular Expansion?
The ABB MG101 is a compact modular expansion for DIN rail-mounted devices within the ABB CombiLine N interior expansion system. Identified by ABB order code 2CPX041200R9999, it is supplied mounted and installed in the cabinet and provides a coordinated 1PW solution for professional sub-distribution assemblies.
Designed for installation devices according to DIN 43880, the MG101 incorporates a 35 × 15 mm DIN rail with perforations for wire holders. The module provides 12 modular space units and supports both 125 mm and 150 mm row spacing, providing flexibility when configuring compatible ABB distribution enclosures.
The MG101 has a nominal height of 150 mm, a width of 250 mm and is suitable for cabinets from 120 mm depth. Plastic covers with cut-outs and a 90-degree press-and-turn closure provide a practical finished assembly, while compatibility with EDF and WR mounting frames supports integration into the wider CombiLine N system.
Key Advantages
- Genuine ABB CombiLine N modular expansion for sub-distribution systems.
- 12 modular space units for DIN rail-mounted installation devices.
- Supports 125 mm and 150 mm row spacing.
- Integrated 35 × 15 mm DIN rail with perforations for wire holders.
- Suitable for compatible cabinets from 120 mm depth.
- Compatible with EDF and WR mounting frames.
Key Features
- ABB CombiLine N interior expansion system.
- MG101 modular expansion.
- 1PW / 1 field width configuration.
- 1 RE / 150 mm nominal height.
- 1 FB / 250 mm nominal width.
- 12 PLE modular space units.
- 125 / 150 mm row spacing.
- DIN rail size of 35 × 15 mm.
- Plastic cover with cut-out and 90-degree press-and-turn closure.
- Suitable for installation devices according to DIN 43880.
- Manufacturer order code 2CPX041200R9999.
Reliable Modular Installation for Distribution Enclosures
DIN rail expansion modules provide an organised internal platform for installing modular electrical devices within distribution enclosures. Standardised rail dimensions and modular spacing help panel builders arrange protective, switching and control devices efficiently while maintaining a structured enclosure layout.
The ABB MG101 combines a 35 × 15 mm DIN rail, 12 modular space units and selectable 125 / 150 mm row spacing within a compact CombiLine N module. Its compatibility with EDF and WR mounting frames makes it a practical solution for professional ABB sub-distribution assemblies.
Typical Applications
- ABB CombiLine N sub-distribution systems.
- DIN rail-mounted modular electrical devices.
- Electrical distribution board assembly.
- Commercial and industrial electrical enclosures.
- Panel building and switchgear installations.
- Expansion of compatible ABB distribution systems.
