Why Choose the ABB MBC204VS SMISSLINE TP Module Expansion?
The ABB MBC204VS is a modular SMISSLINE TP interior expansion module kit designed for vertical device installation within compatible ABB CombiLine sub-distribution assemblies. Supplied under ABB order code 2CPX042166R9999, this unmounted module provides a structured solution for integrating SMISSLINE TP equipment into professional low-voltage distribution cabinets.
Designed specifically for vertical device arrangement, the MBC204VS incorporates 35 × 15 mm DIN rails with perforations for wire holders. The rear DIN rails are intended for standard neutral and protective-earth terminals, while integrated cable-routing provision supports orderly conductor management within the completed distribution assembly.
The MBC204VS has a module height of 4 RE / 600 mm, a width of 2 PW / 500 mm and provides 96 space units. It accommodates a SMISSLINE TP socket-base arrangement of 2 × 30 space units, is suitable for cabinets from 275 mm depth and is supplied as an unmounted kit for installation using the appropriate mounting frame.
Key Advantages
- Purpose-designed SMISSLINE TP module for vertical device installation.
- 2-panel-width / 500 mm format provides generous modular installation capacity.
- Provides 96 space units within the complete module.
- Designed for a 2 × 30 space-unit SMISSLINE TP socket-base arrangement.
- Integrated 35 × 15 mm DIN rails with perforations for wire holders.
- Cable-routing provision supports organised conductor installation.
Key Features
- ABB MBC204VS SMISSLINE TP interior expansion module.
- Designed for vertical device arrangement.
- 4 RE / 600 mm module height.
- 2 PW / 500 mm module width.
- 96 total space units.
- 2 × 30 space-unit socket-base configuration.
- 35 × 15 mm DIN rails with wire-holder perforations.
- Suitable for cabinets from 275 mm depth.
- Plastic covers with cut-outs and RAL 7035 finish.
- 90-degree push-turn closures for the covers.
- Supplied as an unmounted kit.
- ABB order code 2CPX042166R9999.
Flexible SMISSLINE TP Integration for Sub-Distribution Systems
The ABB SMISSLINE TP system provides a modular plug-in platform for compatible protective and switching devices used in low-voltage electrical distribution. The MBC204VS creates a dedicated vertical installation area within a CombiLine cabinet, combining SMISSLINE TP socket-base provision with DIN-rail infrastructure and cable-management facilities for an organised interior layout.
The rear DIN rails are designed to accommodate standard neutral and protective-earth terminals, while the cable-routing grid supports secure and orderly conductor management. With its 2 PW format and 96 space units, the MBC204VS provides increased installation capacity for larger modular distribution assemblies while retaining the flexibility of an unmounted kit.
Typical Applications
- ABB CombiLine modular sub-distribution boards.
- SMISSLINE TP plug-in distribution systems.
- Vertical installation of compatible protective and switching devices.
- Commercial low-voltage distribution cabinets.
- Industrial electrical distribution assemblies.
- Professional switchboard and panel-building applications.
