Why Choose the ABB WR310 WR Mounting Frame 3PW?
The ABB WR310 is a robust WR mounting frame designed for the structured installation of modules and electrical equipment within ABB low-voltage distribution cabinets. As part of the ABB DESUJ Sub Distribution range, it provides a stable internal support structure for compatible floor-standing and row-type switchgear cabinets.
The WR310 is configured for a 3PW / three-field-width installation with an overall height of 2100 mm and 14 height units. It consists of vertical WR profile rails with transverse profile rails, providing a versatile framework for free assembly and modular electrical distribution configurations.
Designed for standing and row-type cabinets with depths from 225 mm, the WR310 can also support installations using the EDF WNF installation set in cabinets from 425 mm deep. Its 750 mm nominal width provides a practical three-field mounting platform for larger modular distribution assemblies.
Key Advantages
- Purpose-designed WR mounting frame for ABB distribution cabinets.
- 3PW / three-field-width configuration for larger modular installations.
- 2100 mm overall height with 14 height units.
- 750 mm nominal width for three-field cabinet arrangements.
- Suitable for standing and row-type cabinets from 225 mm depth.
- Provides a stable framework for free assembly and compatible ABB modules.
Key Features
- ABB DESUJ Sub Distribution range.
- WR mounting frame for modular interior assembly.
- 3PW / three-field-width format.
- 2100 mm overall height.
- 750 mm nominal width.
- 14 height units.
- Vertical WR profile rails with transverse profile rails.
- Suitable for cabinets with depths from 225 mm.
- Compatible with EDF WNF installation arrangements from 425 mm cabinet depth.
- ABB order code 2CPX045236R9999.
Reliable Mounting for Electrical Distribution Assemblies
Mounting frames such as the ABB WR310 provide the structural foundation required to position electrical modules and installation components securely inside low-voltage distribution cabinets. The combination of vertical and transverse profile rails provides panel builders with a practical framework for creating organised and modular electrical assemblies.
The WR mounting system supports free assembly as well as installations incorporating compatible ABB modules and EDF installation equipment. The WR310's three-field-width format makes it particularly suitable where a broader internal mounting structure is required for commercial and industrial power distribution systems.
Typical Applications
- Low-voltage sub-distribution cabinets.
- Standing electrical distribution cabinets.
- Row-type switchgear cabinets.
- Three-field modular electrical panel assemblies.
- EDF WNF installation arrangements.
- ABB cabinet installations requiring a 3PW WR mounting frame.
