Why Choose the ABB ZA5P10 A5 Circuit Diagram Pocket 10-Piece Pack?
The ABB ZA5P10 (order code 2CPX062382R9999) is a practical and reliable A5 self-adhesive circuit diagram pocket designed for storing electrical drawings, wiring diagrams and technical documentation inside electrical distribution boards and control cabinets. Supplied as a pack of 10 document holders, this ABB enclosure accessory provides a convenient solution for organising important electrical documentation and keeping it readily accessible to maintenance engineers and installation personnel.
As part of ABB's DESUJ Sub Distribution product group, the ZA5P10 is designed for use with electrical enclosures, switchboards and distribution systems. Its self-adhesive mounting arrangement simplifies installation without requiring additional fixing screws or drilled mounting holes. The compact A5 format makes it particularly suitable for cabinet doors and internal enclosure surfaces where space is limited.
Manufactured from plastic, the ABB ZA5P10 provides a dedicated storage location for circuit diagrams, installation instructions and equipment documentation. With a product height of 222 mm, width of 192.5 mm and depth of 8 mm, this document pocket is a useful accessory for electrical panel builders, industrial maintenance teams and electrical contractors.
Key Advantages
- Convenient A5 circuit diagram pocket for electrical distribution boards and control cabinets.
- Supplied as a 10-piece pack for multiple installations and enclosure projects.
- Self-adhesive mounting allows straightforward attachment to suitable enclosure surfaces.
- Helps keep wiring diagrams, circuit schedules and technical documentation organised and accessible.
- Compact, space-saving design suitable for electrical cabinet doors and internal panels.
- Durable plastic construction for practical document storage in electrical installations.
- Suitable for use in sub-distribution systems, switchboards and industrial electrical enclosures.
- Genuine ABB enclosure accessory identified by manufacturer order code 2CPX062382R9999.
Key Features
- ABB ZA5P10 A5 circuit diagram pocket.
- Manufacturer order code: 2CPX062382R9999.
- Product group: DESUJ Sub Distribution.
- Document format: DIN A5.
- Pack quantity: 10 pieces.
- Mounting method: Self-adhesive fixing.
- Material: Plastic.
- Product dimensions: 222 mm high × 192.5 mm wide × 8 mm deep.
- Product classification: Wiring diagram pocket / enclosure document holder.
- Designed to provide convenient storage for electrical circuit diagrams and technical documents.
- Suitable for installation on appropriate internal surfaces of electrical enclosures.
- Helps support efficient maintenance, inspection and electrical documentation management.
Reliable Circuit Diagram Storage for Electrical Distribution Systems
Maintaining accurate and accessible electrical documentation is an important part of effective distribution board management. Circuit diagrams, wiring schedules and installation records help electricians and maintenance engineers identify electrical connections, understand system layouts and carry out inspection or maintenance work efficiently. The ABB ZA5P10 circuit diagram pocket provides a dedicated location for storing these documents directly within the associated electrical enclosure.
The self-adhesive A5 document holder can be attached to a suitable clean, dry and flat internal cabinet surface, allowing documentation to remain close to the equipment it describes. Its compact construction helps make efficient use of available space, while the 10-piece pack is particularly convenient for panel builders, contractors and maintenance departments working across multiple distribution boards. As a passive enclosure accessory, the ZA5P10 does not require an electrical supply or connection.
Typical Applications
- Electrical distribution boards and sub-distribution enclosures.
- Industrial electrical control cabinets and switchboards.
- Storage of A5 circuit diagrams and electrical wiring drawings.
- Commercial building electrical installations.
- Industrial automation and machine control panels.
- Electrical panel building and switchgear assembly projects.
- Maintenance documentation and equipment identification records.
- Electrical installation upgrades and refurbishment projects.
- Facilities management and electrical inspection activities.
- OEM electrical enclosure manufacturing and assembly.
