Why Choose the ABB ED234 Extension Frame for Distribution Board Covers?
The ABB ED234 is a purpose-designed extension frame for electrical distribution board covers, developed to provide additional clearance and support correct cover positioning within compatible low-voltage distribution assemblies. As part of the ABB DESUJ Sub Distribution product range, this raising frame is suitable for electrical panel builders and installers working with ABB CombiLine distribution equipment.
The ED234 is specifically designed for the ABB AG34 distribution board cover and provides a practical solution where the cover needs to be raised to accommodate mounting adapters or vertically installed electrical components. Its plastic construction and dedicated dimensions help maintain a consistent, organised installation while supporting the integration of protective covers into distribution board assemblies.
With external dimensions of 600 mm high × 750 mm wide × 50 mm deep, the ABB ED234 is designed for compatible three-field-width distribution configurations. Manufactured from plastic with a light grey RAL 7035 finish, the frame can be used to raise the cover by 25 mm or 35 mm when installed with the appropriate additional components.
Key Advantages
- Purpose-designed extension frame for ABB electrical distribution board covers.
- 600 mm height × 750 mm width for compatible distribution assemblies.
- 50 mm frame depth for raised cover installation arrangements.
- Designed for compatibility with the ABB AG34 cover.
- Supports 25 mm or 35 mm cover raising with the appropriate additional components.
- Durable plastic construction with a RAL 7035 light grey finish.
- Suitable for compatible three-field-width ABB CombiLine distribution assemblies.
- Helps accommodate mounting adapters and vertically arranged electrical components.
Key Features
- ABB ED234 extension / raising frame.
- ABB DESUJ Sub Distribution product range.
- 600 mm external height.
- 750 mm external width.
- 50 mm external depth.
- Three-field-width configuration.
- Plastic frame construction.
- RAL 7035 light grey colour.
- IP2XC protection classification for the specified component.
- Designed for the ABB AG34 distribution board cover.
- Supports raised cover positioning in compatible distribution assemblies.
- Non-transparent and non-hinged construction.
- Quick-fastening design for suitable cover arrangements.
- ABB manufacturer order code: 2CPX062794R9999.
Reliable Cover Positioning for Electrical Distribution Systems
Electrical distribution boards require appropriately positioned covers to accommodate installed components while maintaining an organised and accessible panel layout. Extension frames such as the ABB ED234 provide a practical means of adjusting cover positioning where mounting adapters or vertically installed equipment require additional clearance.
The ED234 is designed for compatible ABB CombiLine distribution assemblies and works with the AG34 cover. When used with the appropriate additional raising components, it allows the cover to be positioned 25 mm or 35 mm higher. This flexibility supports electrical panel construction, modifications and equipment integration while helping maintain the intended arrangement of protective covers within the completed assembly.
Typical Applications
- ABB CombiLine electrical distribution board assemblies.
- Compatible SMISSLINE TP distribution installations.
- Raised mounting arrangements for ABB AG34 covers.
- Low-voltage sub-distribution boards.
- Electrical panels incorporating vertically installed components.
- Commercial and industrial power distribution systems.
- Electrical switchboard construction and panel assembly.
- Distribution board modifications and refurbishment projects.
