Why Choose the ABB Orion Shield-K120 2TLA022313R8300 Lens Shield?
The ABB Orion Shield-K120 2TLA022313R8300 is a purpose-designed lens shield for corresponding ABB Orion2 safety light grids. Part of the ABB Orion safety accessory range, it provides additional protection for the optical surface of compatible Orion2 transmitters and receivers used for non-contact machine safeguarding.
The Orion Shield-K120 is specifically designed for corresponding Orion2-4-K4-120-B and Orion2-4-K4-120-E models. Installed over the front optical area of the compatible Orion2 unit, the shield helps protect the lens against dirt, debris and minor mechanical exposure while maintaining a practical installation for industrial safety applications.
With an overall height of 1342 mm, a width of 36 mm and a depth of 42 mm, the Orion Shield-K120 is dimensioned specifically for its corresponding Orion2 safety light grid. Each package contains the necessary components to protect one transmitter or one receiver, so two shields are required when both units of a transmitter-receiver pair need protection.
Key Advantages
- Purpose-designed lens protection for corresponding ABB Orion2 safety light grids.
- Compatible with Orion2-4-K4-120-B and Orion2-4-K4-120-E models.
- Helps protect the optical surface against dirt, debris and minor mechanical exposure.
- Suitable for compatible Orion2 Base and Orion2 Extended safety equipment.
- 1342 mm overall height matched to corresponding 1200 mm Orion2 light grids.
- Supplied with the necessary components to protect one transmitter or one receiver.
Key Features
- ABB Orion Shield series safety accessory.
- Model Orion Shield-K120.
- Lens shield for corresponding Orion2 equipment.
- Designed for Orion2-4-K4-120-B and Orion2-4-K4-120-E.
- Suitable for Orion2 safety light grids with a 1200 mm height.
- 1342 mm product height.
- 36 mm product width.
- 42 mm product depth.
- Product net weight of approximately 1.50 kg.
- One package protects a single transmitter or receiver.
Reliable Lens Protection for Orion Safety Light Grids
Safety light grids rely on dependable optical transmission and reception to detect access to hazardous areas around machinery. In industrial environments where the front surface of the safety device may encounter dirt, debris or minor physical contact, a dedicated lens shield provides useful additional protection for the optical area.
The ABB Orion Shield range is specifically dimensioned for compatible Orion safety products. The Orion Shield-K120 provides a practical protective solution for corresponding Orion2 units while allowing the safety light grid to remain integrated into machinery, production lines, access protection and perimeter safeguarding systems.
Typical Applications
- Protection of compatible ABB Orion2 safety light grids.
- Industrial machine access protection.
- Perimeter safeguarding around automated machinery.
- Packaging and processing equipment.
- Material handling and conveyor systems.
- Automated assembly and production machinery.
