ABB JSHD4H2A 0,15m 2TLA020002R0200 is a three-position safety enabling device for external mounting, supplied with six 150 mm leads for industrial machine safety and controlled movement applications.
£352.82
The ABB ABB jshd4h2a 0,15m Enabling Switch 2TLA020002R0200 is a compact three-position safety enabling device designed for external mounting on handheld teaching pendants, operator controls and similar industrial equipment. Part of the ABB JSHD4 safety control range, it enables controlled machine movement during tasks where an operator may need to work within or close to a hazardous area.
The JSHD4H2A uses a three-position operating principle to provide deliberate operator control during troubleshooting, test running, programming and machine setup. This arrangement is particularly valuable in applications where certain machine movements must remain possible while normal protective measures are temporarily overridden under controlled safety conditions.
This version is intended for external mounting and is supplied with six 150 mm leads. The JSHD4H2A configuration is the left-hand version, with mounting holes positioned up-left, and its robust IP65 protection rating makes it suitable for demanding industrial environments.
Three-position enabling devices provide an important operator interface for machinery that may need limited controlled movement while personnel are performing setup, commissioning or diagnostic work. The three-position principle requires deliberate actuation, helping ensure that movement is enabled only while the operator maintains the intended operating position.
The ABB JSHD4H2A is particularly suited to integration on the rear of handheld teaching pendants and similar operator devices. Its external mounting arrangement, compact construction and six pre-wired leads simplify incorporation into machinery safety control systems while supporting demanding industrial operating conditions.
| Current | 2 A |
|---|---|
| Manufacturer | ABB |
| Series | JSHD4 |
| Model | JSHD4H2A 0,15m |
| Order code | 2TLA020002R0200 |
| Product type | Safety enabling switch / three-position enabling device |
| Number of positions | 3 |
| Mounting | External mounting |
| Hand / mounting orientation | Left |
| Lead configuration | 6 leads |
| Lead length | 150 mm |
| Switching contact type | Quick-break |
| Change-over contacts | 2 |
| Rated operational current at DC-12, 24 V | 0.02 A |
| Protection rating | IP65 |
| Safety performance | PL e according to EN ISO 13849-1 |
| Suitable for safety functions | Yes |
| Cross-wire monitoring | Possible |
| GTIN / EAN | 7350024454833 |
| HS Code | 85365019 |
| Country of Manufacture | Sweden |
It is a three-position safety enabling device used to permit controlled machine movement during activities such as troubleshooting, test running, setup and programming.
The ABB JSHD4H2A is a three-position enabling device, providing deliberate operator control for safety-related machine operations.
This version is supplied with six leads, each 150 mm long, for connection to the machine safety control system.
The 2TLA020002R0200 is designed for external mounting, typically on the rear of a handheld teaching pendant or similar operator control device, and is the left-hand mounting version.
The enabling device has an IP65 protection rating, providing protection suitable for demanding industrial operating environments.
ABB JSHD4 safety enabling devices are designed for machine safety applications where operators require dependable, deliberate control of limited machine movement during programming, setup, testing and troubleshooting operations.
