ABB JSTD1-A 2TLA020007R3000 is an IP67 Safeball safety control device with 1 NO and 1 NC independent contacts, a 2 m cable and an ergonomic two-button design for industrial machine-control applications.
£174.63
The ABB ABB jstd1-a 2TLA020007R3000 is an ergonomic JSTD1-A Safeball safety control device designed for one-hand and, when two units are used together with an appropriate safety controller, two-hand machine control applications. Part of the ABB Jokab Safety JSTD1 Safeball range, its spherical design incorporates two independently operated pushbuttons that must both be pressed to provide an operating signal.
The Safeball concept helps reduce the possibility of accidental actuation while providing a comfortable operator interface with several possible grip positions. The JSTD1-A requires a relatively low operating force of approximately 2 N, making it suitable for repetitive industrial operations where both safety and operator ergonomics are important.
This JSTD1-A version incorporates 1 NO + 1 NC independent contacts and is supplied with a 2 m four-conductor cable. It supports a maximum resistive load of 30 V DC, 2 A, while its polypropylene body and IP67 protection rating provide durability for demanding industrial machine-control environments.
The ABB Safeball concept provides an ergonomic alternative to conventional palm buttons for machine control. Each spherical JSTD1 device contains two pushbuttons positioned so that both must be deliberately pressed to operate the connected control circuit, helping reduce the possibility of accidental actuation while allowing several natural grip positions.
For two-hand safety applications, two Safeball devices are normally used together with a suitable safety relay or safety PLC. The operator must then actuate the required buttons on both Safeballs to permit machine operation. Releasing one or more buttons generates a stop signal, making the arrangement particularly suitable for machinery where the operator's hands must remain away from a hazardous operating zone.
| Manufacturer | ABB |
|---|---|
| Series | JSTD1 Safeball |
| Model | JSTD1-A |
| Order code | 2TLA020007R3000 |
| Product type | Safeball safety control device |
| Control arrangement | Two integrated pushbuttons |
| Contact configuration | 1 NO + 1 NC independent contacts |
| Cable length | 2 m |
| Cable conductors | 4 |
| Maximum switching voltage | 30 V DC |
| Maximum resistive load | 2 A |
| Activation force | Approx. 2 N |
| Protection rating | IP67 |
| Body material | Polypropylene |
| Dimensions | Approx. 68.5 × 68 × 70 mm |
| Product net weight | Approx. 0.23 kg |
| GTIN / EAN | 7350024460193 |
| HS Code | 85364110 |
| Country of Manufacture | Sweden |
The JSTD1-A is an ABB Safeball safety control device containing two integrated pushbuttons and 1 NO + 1 NC independent contacts for industrial machine-control applications.
Yes. Two Safeball devices can be used together with a suitable safety controller to create a two-hand control system in which the operator must deliberately actuate both devices to permit machine operation.
The JSTD1-A is supplied with a 2 m four-conductor cable, providing flexibility when positioning the Safeball around machinery and operator stations.
The ABB JSTD1-A incorporates 1 normally open and 1 normally closed independent contact, with a maximum resistive load of 30 V DC at 2 A.
The JSTD1-A has an IP67 protection rating and a polypropylene body, making it suitable for demanding industrial operating environments.
ABB Jokab Safety JSTD1 Safeball devices provide machine builders, system integrators and industrial operators with an ergonomic and dependable control solution for safety-related one-hand and two-hand machine operating applications.
