Why Choose the IMO BX10SR/0A-HB6XLS Photo-Electric Area Sensor?
The IMO BX10SR/0A-HB6XLS is a BX10 series through-beam photo-electric area sensor kit comprising a matched transmitter and receiver for reliable object detection in industrial automation applications. With 10 optical beams, a 90 mm active sensing height and 10 mm beam spacing, it provides wider-area detection than a conventional single-beam photoelectric sensor.
Designed for sensing ranges from 0.3 to 4 m, the BX10SR/0A-HB6XLS uses 4-pin M12 connectors for straightforward industrial wiring. The receiver provides both PNP and NPN normally-open switching capability, helping the sensor integrate with a wide range of PLC and machine-control architectures operating from a 10 to 26 V DC supply.
This particular BX10 configuration incorporates an anti-interference strobe-light filter, helping maintain dependable detection where external flashing or stroboscopic light sources could otherwise interfere with optical sensing. An IP67 enclosure and compact 107 × 36 × 20 mm profile make the sensor kit well suited to demanding machinery and automated handling installations.
Key Advantages
- Complete through-beam transmitter and receiver kit for industrial area detection.
- 10 optical beams provide reliable detection across a 90 mm sensing height.
- Extended sensing distance of 0.3 to 4 m.
- 10 mm channel spacing supports detection of relatively small objects passing through the sensing field.
- Integrated anti-interference filter helps minimise disturbance from stroboscopic lighting.
- Combined PNP and NPN output provides flexible controller integration.
- 4-pin M12 connection simplifies installation and replacement.
- IP67 protection supports reliable use in industrial environments.
Key Features
- IMO BX10 series photo-electric area sensor.
- Manufacturer reference BX10SR/0A-HB6XLS.
- Through-beam sensing principle.
- Supplied as transmitter + receiver.
- 10-beam optical array.
- 90 mm active sensing height.
- 10 mm optical channel spacing.
- Operating range of 0.3 to 4 m.
- PNP + NPN normally-open output.
- 4-pin M12 connector.
- Integrated anti-interference strobe-light filtering.
- Glass optical surface.
- Compact plastic rectangular housing.
- IP67 enclosure protection.
Reliable Multi-Beam Detection for Industrial Automation
Unlike a conventional single-point photoelectric sensor, the IMO BX10SR/0A-HB6XLS creates a 90 mm high multi-beam detection field between its transmitter and receiver. An object interrupting the optical field can therefore be detected across a broader area, making the system particularly useful for product presence, component detection, counting and material-handling applications where object position may vary.
The 0.3 to 4 m operating range provides flexibility for machinery of different widths, while the dedicated anti-interference feature helps maintain reliable sensing around stroboscopic or flashing light sources. Combined with IP67 protection, M12 connectivity and dual PNP/NPN output capability, the BX10SR/0A-HB6XLS provides a versatile area-sensing solution for modern automated equipment.
Typical Applications
- Product and component presence detection.
- Conveyor and material-handling systems.
- Object counting and monitoring.
- Packaging and processing machinery.
- Automated assembly equipment.
- Parts detection across variable positions.
- Warehouse and logistics automation.
- Industrial machinery exposed to interfering or stroboscopic light sources.
