Why Choose the IMO BX10SR/0C-HB6XLS Photo-Electric Area Sensor?
The IMO BX10SR/0C-HB6XLS is a BX10 series through-beam photo-electric area sensor kit comprising a matched transmitter and receiver for reliable object detection in industrial automation applications. Its 10 optical beams, 90 mm active sensing height and 10 mm beam spacing create a compact sensing field capable of detecting products and components across a wider area than a conventional single-beam photoelectric sensor.
Designed for sensing distances from 0.3 to 4 m, the BX10SR/0C-HB6XLS operates from a 10 to 26 V DC supply and uses industrial 4-pin M12 connectors. The receiver provides both PNP and NPN light-on switching outputs, giving machine builders flexibility when integrating the sensor with different PLC and industrial control architectures.
This version also incorporates a strobe-light anti-interference function, helping maintain dependable optical detection in environments where flashing or stroboscopic lighting may otherwise disturb the sensing system. Combined with an IP67 enclosure, compact rectangular construction and adjustable sensing system, the BX10SR/0C-HB6XLS is well suited to automated production, packaging and material-handling machinery.
Key Advantages
- Complete through-beam transmitter and receiver kit.
- 10 optical beams provide detection across a 90 mm active sensing height.
- 10 mm beam spacing supports accurate detection of products and components.
- Extended sensing range of 0.3 to 4 m.
- PNP and NPN light-on outputs provide flexible control-system integration.
- Integrated strobe-light anti-interference function improves reliability around interfering light sources.
- 4-pin M12 connection supports straightforward industrial installation.
- IP67 protection makes the sensor suitable for demanding automation environments.
Key Features
- IMO BX10 series photo-electric area sensor.
- Manufacturer reference BX10SR/0C-HB6XLS.
- Through-beam sensing principle.
- Supplied as a transmitter and receiver pair.
- 10-beam optical array.
- 90 mm active sensing height.
- 10 mm optical beam spacing.
- 0.3 to 4 m sensing range.
- PNP + NPN light-on switching output.
- Adjustable sensing system.
- 4-pin M12 connector.
- Strobe-light anti-interference functionality.
- Compact plastic rectangular housing.
- IP67 enclosure protection.
Reliable Multi-Beam Detection with Light-On Switching
The IMO BX10SR/0C-HB6XLS creates a 90 mm high optical detection field between its transmitter and receiver rather than relying on a single sensing point. With 10 optical beams arranged at 10 mm intervals, the sensor is suitable for detecting products, components and other objects whose exact position may vary as they move through automated machinery.
The 0C configuration provides light-on switching, distinguishing it from dark-on versions within the BX10 family. Its 4 m maximum sensing range, dual PNP/NPN output capability and strobe-light anti-interference functionality provide a versatile solution for installations requiring dependable area sensing in electrically and optically challenging industrial environments.
Typical Applications
- Product and component presence detection.
- Conveyor and material-handling systems.
- Automated product counting and monitoring.
- Packaging and processing machinery.
- Automated assembly equipment.
- Parts detection across variable positions.
- Warehouse and logistics automation.
- Industrial installations exposed to flashing or stroboscopic lighting.
