Why Choose the IMO C30M/BN-1E Capacitive Proximity Sensor?
The IMO C30M/BN-1E is a robust M30 capacitive proximity sensor designed for reliable non-contact detection in industrial machinery and automation systems. Featuring a stainless steel cylindrical housing and shielded mounting configuration, it provides dependable detection of metallic and non-metallic materials where conventional inductive sensing may not be suitable.
This sensor operates from a 10–40 V DC supply and provides complementary NPN normally open and normally closed (NO+NC) outputs. Its adjustable sensitivity allows the detection point to be optimised for the target material and installation, while a yellow LED provides convenient visual indication when an object is detected.
With an adjustable nominal sensing distance of 2–16 mm, a 30 Hz switching frequency and an industrial M12 plug connection, the C30M/BN-1E is well suited to machine sensing, level detection and automated material-handling applications. Its stainless steel M30 housing and IP67 protection rating provide durability for demanding industrial environments.
Key Advantages
- Industrial M30 capacitive proximity sensor for non-contact object detection.
- Adjustable 2–16 mm nominal sensing distance provides flexible detection setup.
- 10–40 V DC operating voltage suits common industrial control systems.
- Complementary NPN NO+NC outputs provide flexible control integration.
- Durable stainless steel housing for demanding machinery applications.
- Shielded mounting supports installation within surrounding material.
- Standard M12 plug simplifies sensor installation and replacement.
- IP67 protection provides resistance to dust and water ingress.
Key Features
- IMO C30M Series capacitive proximity sensor.
- M30 cylindrical stainless steel housing.
- Shielded installation.
- 2–16 mm adjustable nominal sensing distance.
- NPN NO+NC switching outputs.
- 30 Hz switching frequency.
- 10–40 V DC operating supply.
- Maximum load current of 200 mA.
- Yellow LED for object-detected indication.
- Adjustable sensitivity for application-specific detection.
- Short-circuit and reverse-polarity protection.
- M12 plug electrical connection.
Reliable Non-Contact Detection for Industrial Automation
Capacitive proximity sensors detect changes in capacitance produced when a target enters the sensor's electric field. Unlike sensing technologies limited primarily to metals, capacitive sensors can detect a wide variety of materials, making them useful for detecting products, liquids, powders and other materials in automated industrial processes.
The IMO C30M/BN-1E combines adjustable sensitivity with complementary NPN outputs and a rugged stainless steel M30 housing. Its M12 connection, IP67 protection and integrated electrical protection functions support reliable installation in production machinery, conveying equipment and industrial process-control systems.
Typical Applications
- Industrial object and presence detection.
- Liquid and bulk-material level sensing.
- Packaging and production machinery.
- Conveyor and material handling systems.
- Plastic, glass and non-metallic object detection.
- Automated manufacturing equipment.
- Machine positioning and process monitoring.
- Industrial automation and control systems.
