IMO C30P/BP-1E is a shielded M30 capacitive proximity sensor with an adjustable 2–16 mm sensing range, 10–40 V DC supply and complementary PNP NO and NC outputs.
Original price was: £175.67.£132.35Current price is: £132.35.
The IMO C30P/BP-1E is a robust M30 capacitive proximity sensor designed for reliable non-contact detection of metals, plastics, glass, ceramics, wood, powders, granulates and liquids. As part of the versatile IMO C30 sensor series, it combines adjustable sensitivity with a durable thermoplastic polyester housing for industrial automation and process-control applications.
Unlike inductive sensors that primarily detect metallic objects, the C30P/BP-1E uses capacitive sensing technology to detect both conductive and non-conductive materials. Its adjustable sensing range allows the sensor to be configured for different targets and operating conditions, while the yellow LED provides a clear visual indication whenever an object is detected.
With a nominal sensing distance adjustable from 2–16 mm, a 10–40 V DC supply and complementary PNP normally open and normally closed outputs, the C30P/BP-1E provides flexible integration with PLCs and industrial control systems. Its shielded, flush-mountable M30 body and four-pin M12 connector simplify installation in machinery, tanks, packaging equipment and material-handling systems.
Capacitive proximity sensors detect changes in an electrical field when a target approaches the sensing face. This enables the IMO C30P/BP-1E to identify a broad range of conductive and non-conductive materials, including products that cannot be reliably detected by conventional inductive proximity switches.
The adjustable sensitivity makes the sensor suitable for detecting materials through certain non-metallic container walls, monitoring fill levels and confirming the presence of products or components. Its protected DC electronics, complementary outputs and industrial M12 connection support reliable integration into automated machinery and PLC-controlled processes.
| HS Code | 8536508000 |
|---|---|
| Country of Manufacture | Lithuania |
| Manufacturer | IMO Precision Controls |
| Series | C30 |
| Model | C30P/BP-1E |
| Product type | Capacitive proximity sensor |
| Nominal sensing distance | 2–16 mm, adjustable |
| Operating voltage | 10–40 V DC |
| Output type | PNP |
| Output function | Normally open and normally closed |
| Switching frequency | 30 Hz |
| Maximum load current | 200 mA |
| No-load supply current | ≤12 mA |
| Leakage current | ≤100 µA |
| Output voltage drop | 2.5 V maximum at 200 mA |
| Repeat accuracy | 5% |
| Hysteresis | ≤20% |
| Protection rating | IP67 |
| Mounting type | Shielded / flush mounting |
| Housing | M30 cylindrical thread |
| Housing material | Thermoplastic polyester |
| Connection | Four-pin M12 plug |
| Dimensions | M30 × 79 mm |
| Operating temperature | -25 to +80 °C |
| Weight | approx. 100 g |
| Approvals | CE and cULus |
This sensor provides non-contact detection of metals, plastics, glass, ceramics, wood, powders, granulates and liquids in industrial automation and process-control applications.
The C30P/BP-1E has an adjustable nominal sensing distance of 2–16 mm, allowing its sensitivity to be configured for the target material and installation.
The C30P/BP-1E operates from a 10–40 V DC supply.
The sensor provides complementary PNP normally open and normally closed outputs, enabling flexible connection to PLCs and control equipment.
Yes. Its shielded M30 construction is designed for flush mounting, and the sensor connects through a standard four-pin M12 plug.
IMO C30 capacitive proximity sensors provide versatile, dependable detection of conductive and non-conductive materials, helping automation engineers monitor products, materials and process levels across demanding industrial applications.{ "@context": "https://schema.org/", "@type": "Product", "name": "IMO C30P/BP-1E M30 Capacitive Proximity Sensor", "sku": "C30P/BP-1E", "mpn": "C30P/BP-1E", "brand": { "@type": "Brand", "name": "IMO" }, "category": "Capacitive Proximity Sensors", "description": "IMO C30P/BP-1E is a shielded M30 capacitive proximity sensor with an adjustable 2–16 mm sensing range, 10–40 V DC supply and complementary PNP NO and NC outputs.", "additionalProperty": [ { "@type": "PropertyValue", "name": "Sensing distance", "value": "2–16 mm adjustable" }, { "@type": "PropertyValue", "name": "Operating voltage", "value": "10–40 V DC" }, { "@type": "PropertyValue", "name": "Output", "value": "PNP NO and NC" }, { "@type": "PropertyValue", "name": "Connection", "value": "Four-pin M12 plug" }, { "@type": "PropertyValue", "name": "Protection rating", "value": "IP67" } ] } { "@context": "https://schema.org", "@type": "FAQPage", "inLanguage": "en-GB", "mainEntity": [ { "@type": "Question", "name": "What is the IMO C30P/BP-1E used for?", "acceptedAnswer": { "@type": "Answer", "text": "This sensor provides non-contact detection of metals, plastics, glass, ceramics, wood, powders, granulates and liquids in industrial automation and process-control applications." } }, { "@type": "Question", "name": "What is the sensing range of this sensor?", "acceptedAnswer": { "@type": "Answer", "text": "The C30P/BP-1E has an adjustable nominal sensing distance of 2–16 mm, allowing its sensitivity to be configured for the target material and installation." } }, { "@type": "Question", "name": "What supply voltage does the sensor require?", "acceptedAnswer": { "@type": "Answer", "text": "The C30P/BP-1E operates from a 10–40 V DC supply." } }, { "@type": "Question", "name": "What output configuration does the C30P/BP-1E provide?", "acceptedAnswer": { "@type": "Answer", "text": "The sensor provides complementary PNP normally open and normally closed outputs, enabling flexible connection to PLCs and control equipment." } }, { "@type": "Question", "name": "Can the IMO C30P/BP-1E be mounted flush?", "acceptedAnswer": { "@type": "Answer", "text": "Yes. Its shielded M30 construction is designed for flush mounting, and the sensor connects through a standard four-pin M12 plug." } } ] }
