Why Choose the Carlo Gavazzi CL3 Rectangular Magnetic Actuator?
The Carlo Gavazzi CL3 is a compact rectangular magnetic actuator designed for use with compatible magnetic proximity sensing systems in industrial automation and machine applications. Part of the Carlo Gavazzi CL series, the CL3 uses an Alnico magnetic element housed within a durable rectangular plastic enclosure.
Designed as a passive magnetic target, the CL3 provides the magnetic field required to actuate a compatible magnetic sensor without requiring an electrical supply or wiring connection. This makes it a simple and dependable solution for position detection, presence sensing and non-contact switching applications where mechanical contact between the actuator and sensor is undesirable.
The CL3 measures 18 × 59 × 9 mm and features a rectangular plastic housing suited to straightforward mounting on moving machine parts, guards, doors and other monitored components. Carlo Gavazzi specifies a minimum separation of 30 mm between two CL3 magnets, helping maintain reliable magnetic sensing when multiple actuators are installed in the same application.
Key Advantages
- Compact rectangular magnetic actuator for industrial sensing applications.
- Uses a durable Alnico magnetic element.
- Robust plastic housing for practical machine installation.
- Compact 18 × 59 × 9 mm dimensions.
- Passive magnetic operation requires no external electrical supply.
- Supports reliable non-contact position and presence detection with compatible magnetic sensors.
Key Features
- Carlo Gavazzi CL series magnetic actuator.
- Rectangular housing format.
- Alnico magnetic material.
- Plastic housing construction.
- 18 mm height.
- 59 mm length.
- 9 mm depth.
- Recommended minimum separation between two magnets: 30 mm.
- Designed for use with compatible magnetic proximity sensors.
Reliable Magnetic Actuation for Position Sensing
Magnetic actuators such as the Carlo Gavazzi CL3 provide a permanent magnetic target for compatible proximity sensors. When the actuator enters the sensor's detection zone, the magnetic field can trigger the sensing element without requiring physical contact, helping reduce mechanical wear and providing dependable detection of moving components.
The CL3's passive construction makes installation straightforward because the actuator itself requires no power supply or electrical wiring. Its compact rectangular format is particularly useful for machine doors, moving assemblies, position-monitoring systems and other automation applications where a robust magnetic target is required.
Typical Applications
- Industrial magnetic proximity sensing systems.
- Machine position and presence detection.
- Automation equipment and production machinery.
- Door and access-panel position monitoring.
- Moving component and mechanism detection.
- Material handling and conveyor equipment.
