Why Choose the Carlo Gavazzi EI1202NPOSL Inductive Proximity Sensor?
The Carlo Gavazzi EI1202NPOSL is a robust and reliable M12 inductive proximity sensor designed for non-contact detection of metallic objects in industrial automation and machinery applications. As part of the established Carlo Gavazzi EI series, it combines a durable stainless steel threaded housing with dependable NPN normally open switching for straightforward integration into industrial control systems.
This sensor provides a nominal sensing distance of 2 mm and is designed for flush mounting in metal, allowing it to be installed neatly within machinery, fixtures and equipment. Its long-body construction provides practical mounting flexibility, while the integrated cable connection helps simplify wiring and commissioning.
With a 10–32 V DC supply, maximum output current of 200 mA and switching frequency of up to 800 Hz, the EI1202NPOSL is well suited to position detection, presence sensing, counting and machine automation. Its IP67 stainless steel construction provides dependable protection for demanding industrial environments.
Key Advantages
- Compact M12 inductive proximity sensor for metallic object detection.
- 2 mm nominal sensing distance for precise short-range detection.
- NPN normally open output for integration with compatible PLC and control inputs.
- Durable stainless steel cylindrical threaded housing.
- Flush-mountable design simplifies installation within machinery and metal structures.
- IP67 protection supports reliable operation in demanding industrial environments.
Key Features
- Carlo Gavazzi EI series inductive proximity sensor.
- M12 threaded cylindrical housing.
- 2 mm nominal sensing distance.
- NPN normally open switching output.
- 10–32 V DC supply voltage.
- 200 mA maximum output current.
- 800 Hz maximum switching frequency.
- 2 m integrated cable connection.
- Long-body configuration for flexible machine installation.
- LED indication for output status.
- Short-circuit and reverse-polarity protection.
- IP67 rated enclosure.
Reliable Non-Contact Detection for Industrial Automation
Inductive proximity sensors such as the Carlo Gavazzi EI1202NPOSL detect metallic targets without requiring physical contact. This reduces mechanical wear compared with conventional limit switches and enables reliable position, presence and movement detection across automated machinery and production equipment.
The EI series is designed for industrial automation applications where compact dimensions, reliable switching and robust construction are important. The EI1202NPOSL's stainless steel M12 housing, flush mounting capability and protected DC electronics make it suitable for integration into machine frames, conveyors, handling systems and automated production equipment.
Typical Applications
- Industrial machinery position detection.
- Conveyor and material handling systems.
- Metal component presence detection.
- Automated production and assembly equipment.
- Packaging machinery.
- Counting and positioning applications.
- Machine tools and manufacturing equipment.
- PLC-controlled industrial automation systems.
