Why Choose the Carlo Gavazzi EI1808TBCPL-6 Inductive Proximity Sensor?
The Carlo Gavazzi EI1808TBCPL-6 is a robust M18 inductive proximity sensor designed for reliable non-contact detection of metallic targets in industrial machinery and automation systems. Part of the Carlo Gavazzi EI18 sensor range, it combines a long-body thermoplastic polyester housing with an M12 connector and 2-wire AC switching technology for straightforward integration into industrial equipment.
The EI1808TBCPL-6 provides a rated operating distance of 8 mm and features an SCR normally closed (NC) output. Its inductive sensing principle detects metallic targets without physical contact, helping minimise mechanical wear while providing dependable switching for repetitive position, presence and limit-detection applications.
Operating from a 20–250 V AC supply, the sensor supports a maximum output current of 500 mA and a maximum switching frequency of 25 Hz. Its M18 construction, M12 connector, IP67 protection and operating temperature range of -25 to +70 °C make it well suited to demanding industrial automation applications.
Key Advantages
- Reliable non-contact detection of metallic targets for industrial automation.
- 8 mm rated operating distance provides extended sensing capability.
- 2-wire SCR normally closed output for compatible AC control circuits.
- Robust M18 thermoplastic polyester housing for industrial applications.
- M12 connector simplifies installation, servicing and sensor replacement.
- 500 mA maximum output current for compatible switching loads.
- IP67 protection supports dependable operation in demanding environments.
Key Features
- Carlo Gavazzi EI18 inductive proximity sensor range.
- M18 cylindrical threaded barrel.
- 8 mm rated operating distance.
- Long-body construction.
- 2-wire SCR normally closed (NC) output.
- 20–250 V AC rated power supply.
- 500 mA maximum output current.
- 25 Hz maximum switching frequency.
- Thermoplastic polyester housing.
- M12 connector for convenient field connection.
- Yellow LED output-status indication.
- IP67 ingress protection.
- -25 to +70 °C operating temperature range.
Reliable AC Inductive Sensing for Industrial Automation
Inductive proximity sensors detect metallic objects by monitoring changes in an electromagnetic sensing field, allowing targets to be detected without mechanical contact. This contactless operating principle helps reduce physical wear and provides dependable switching for repetitive machine positioning, component detection and process-monitoring duties.
The EI1808TBCPL-6 combines an 8 mm sensing distance with 2-wire AC SCR switching and a convenient M12 connector. Its long M18 thermoplastic polyester body and normally closed output make it a practical choice for machine builders and automation engineers requiring reliable metallic-object detection in AC control systems.
Typical Applications
- Industrial machinery position detection.
- Metal component presence sensing.
- Conveyor and material handling systems.
- Automated assembly and production equipment.
- Packaging and processing machinery.
- Industrial AC control and machine automation systems.
