Why Choose the Carlo Gavazzi EI3015PPOPL Inductive Proximity Sensor?
The Carlo Gavazzi EI3015PPOPL is a robust M30 inductive proximity sensor designed for reliable non-contact detection of metallic objects in industrial machinery and automation systems. Part of the Carlo Gavazzi EI30 series, this long-body sensor combines a thermoplastic cylindrical threaded housing with a PNP normally open output for straightforward integration into DC control systems.
With a 15 mm rated operating distance, the EI3015PPOPL provides extended-range detection of conductive metal targets without requiring physical contact. Its non-flush sensing configuration is suitable for applications where additional sensing distance is required, while solid-state switching helps minimise mechanical wear in high-cycle industrial automation.
The EI3015PPOPL operates from a 10–40 V DC supply, supports up to 200 mA output current and provides a maximum switching frequency of 100 Hz. A 2 m cable, IP67 protection and an operating temperature range of -25 to +70 °C make it well suited to conveyors, production machinery, material handling equipment and general factory automation.
Key Advantages
- Reliable non-contact detection of metallic targets.
- 15 mm rated sensing distance for extended-range industrial detection.
- M30 thermoplastic threaded housing with a long-body design.
- PNP normally open output for compatible DC automation systems.
- 2 m cable provides straightforward connection to control equipment.
- IP67 protection supports operation in demanding industrial environments.
Key Features
- Carlo Gavazzi EI30 series inductive proximity sensor.
- M30 cylindrical threaded barrel.
- 15 mm rated operating distance.
- Non-flush mounting sensing configuration.
- PNP normally open transistor output.
- 10–40 V DC rated supply voltage.
- Maximum 200 mA output current.
- Maximum 100 Hz switching frequency.
- Thermoplastic housing with long-body construction.
- 2 m cable connection.
- IP67 protection rating.
Reliable Metal Detection for Industrial Automation
Inductive proximity sensors detect conductive metallic objects through an electromagnetic sensing field, allowing machinery to monitor component presence and position without mechanical contact. This contactless operating principle provides repeatable switching while reducing physical wear compared with conventional mechanical sensing devices.
The Carlo Gavazzi EI3015PPOPL combines a 15 mm sensing distance, M30 thermoplastic construction and PNP normally open switching with a practical 2 m cable. Its non-flush configuration and IP67 protection make it a dependable choice for machine builders and automation engineers requiring extended-range metal detection in industrial equipment.
Typical Applications
- Industrial machine position and presence detection.
- Conveyor and material handling systems.
- Automated production and assembly machinery.
- Metal component detection and counting.
- Packaging and processing equipment.
- Factory automation and machine control systems.
